Warranty Information
No warranty information found in the provided pages.
- Turning on/off the unit: Press POWER on the front panel or DVD POWER on the remote control.
- Inserting and removing discs: Press OPEN/CLOSE to open/close the disc tray and place the disc.
- Basic playback: Press PLAY to start playback from the beginning. Press STOP to stop playback completely. Press PAUSE to stop temporarily.
- Rapid advance/reverse playback: Use the SHUTTLE knob or the fast forward/rewind buttons on the remote.
- Resuming playback: Press RESUME to store the current playback position for later resumption.
Troubleshooting and error codes
| Symptom | Possible case | Remedy |
|---|---|---|
| Power does not come on. | Power plug is not inserted securely. | Plug in securely. |
| Remote control does not work. | Too far from the unit. | More closer to the unit. |
| The tip of the remote unit is not pointed in the right direction. | Point the infrared light- emitting window toward the remote sensor on the front panel. | |
| Batteries are exhausted. | Replace the batteries with new ones. | |
| Battery polarity is incorrect. | Take out the batteries and insert them again in the correct direction. | |
| No picture is displayed on the monitor. | Connection of video cable is incorrect. | Connect the cable correctly. |
| Input selection of TV is incorrect. | Select correctly. | |
| Disc is not playable. | Use a playable disc. (See page 11.) | |
| Picture is noisy. | The unit is connected to a VCR directly and the copyguard function is activated. | Connect the unit so that the picture signal flows directly to the TV. |
| No audio is reproduced. | Connection is incorrect. | Check the connections. |
| Input selection of amplifier is incorrect. | Select correctly. | |
| No audio is reproduced when playing back a DVD disc recorded with 96-kHz, linear PCM audio. | The audio signal derives from the unit's DIGITAL OUT. | Use the AUDIO OUT when playing back such discs. |
| Sound is distorted or noise is generated. | Disc is dirty. | Wipe the disc surface. |
| Picture is garbled. | The screen saver mode is set to MODE 1, and the screen saver function is activated. | Set the screen saver mode to the other mode. |
| Picture does not fit the television screen. | MONITOR TYPE is not correctly set. | Select monitor type correctly. (See page 35.) |
| Television is not correctly set. | Set the television correctly. | |
| Operation is not possible. | Microcomputer malfunctions due to lightning or static electricity. | Turn off the power and unplug the power cord, then connect the power cord again. |
| Moisture condensation occurs by a sudden change of temperature or humidity. | Turn off the power, then turn it on a few hours later. |
