Manual for XL-Z132BK/XL-Z232BK
Uploaded: Nov. 21, 2025, 9:16 p.m.
Warranty Information
This is a limited warranty for one year on parts and labor in the US, DC, and Puerto Rico.
- Turning on the power: Press the POWER button. The unit turns on and the display activates. Press again to standby or disconnect the power cord for a full shutdown.
- Loading a disc: Press OPEN/CLOSE to open the tray, place the disc with the label side up, then press OPEN/CLOSE to close.
- Playing a disc: Press the PLAY (►) or PLAY/PAUSE (►/II) button.
- Stopping playback: Press the STOP (■) button.
- Skipping tracks: Use the◄◄ or ►►► buttons to move to the beginning or next track, respectively.
- Searching: Press and hold the ◄◄ or ►►► SEARCH buttons for fast forward or backward playback.
- Programmed playback: Use the PROGRAM button to select and play tracks in a desired order.
- Random playback: Press the RANDOM button to play tracks in a random order.
- Repeat playback: Use the REPEAT (ALL/1) button to repeat the whole disc or a single track.
Troubleshooting and error codes
| Symptom | Possible cause | Remedy |
|---|---|---|
| The unit is not operative. | Power plug is disconnected from the AC outlet. | Connect the plug to an AC outlet. |
| The AC power cord plug is disconnected from the AC power cord inlet of this unit. | Connect the plug to an AC power cord inlet. | |
| The remote control unit does not function. (XL-Z232BK only) | Disc is not loaded. | Load a disc in the disc tray. |
| Batteries are exhausted. | Replace both batteries. | |
| There is an obstacle between remote control unit and the remote sensor of the main unit. | Remove the obstacle. | |
| Direct sunlight shines on the remote sensor of the main unit. | Shade the unit from the direct sunlight. | |
| Playback is not possible. | Disc is inserted upside down. | Load a disc with its label-side up in the disc tray. |
| Disc is not loaded in the correct position. | Load the disc according to the groove of the disc tray. | |
| Moisture is condensed inside the unit. | Leave the unit turned on until the moisture evaporates. | |
| The reproduced sound includes noise. | Disc is dirty. | Wipe off the disc surface with a soft cloth. |
| Disc is warped. | Replace the disc with a new one. | |
| Disc is scratched. | Replace the disc with a new one. |
