Spec Sheet for PS-HL-138xxBM Series

Spec Sheet for PS-HL-138xxBM Series

Brand: Honeywell

Category: Security System

Document Type: Spec Sheet

Language: EN

Uploaded: Nov. 21, 2025, 6:25 p.m.

Manual Publish Date: 2020-03-01

Warranty Information

Refer to the battery manufacturer's documentation for battery life and replacement.

  • High efficiency cost-effective power supply range ideal for Access Control applications.
  • Features a regulated 13.8V dc output supplying continuous full rated current to load and a universal mains voltage input.
  • Standby battery recharging is achieved within 24h for an 18Ah battery.
  • Deep discharge protection for maximum battery life.
  • Two sets of volt-free contacts for signalling mains and battery/output faults.
  • Models include 5A with 4 x 1.25A fused outputs and 10A with 8 x 1.25A fused outputs.

Troubleshooting and error codes

Local Indicators Mains present
MAINS LED (Green) Flashes (1s period) when: loss of mains, battery disconnected, output fuse fail, battery fuse fail, output short circuit or low output voltage
FAULT LED (Red)* Mains present
