Manual for HPF-PS6(E)(B) & HPF-PS10(E)(B)

The HPF-PS6 and HPF-PS10 are remote power supplies with battery chargers. They provide ADA compatible strobe synchronization and a filtered 24 VDC output for Notification Appliance Circuits (NACs).

Key features include:

• Operation in Default or Retrofit Mode.
• Self-contained in a lockable cabinet.
• Power-limited Class 2 outputs.
• Multiple optically-isolated input/command circuits.
• Configurable output circuits for NACs, special application power, or door holder outputs.
• Individual NAC power and trouble LEDs.
• Integral supervised battery charger.
• Fully supervised power supply, battery, and NACs.
• Selectable strobe synchronization.
• Ground fault detection.

The system can be used as a master or slave unit in various applications, including NAC extension and synchronization.
