Manual for PENTAX H3

1. Cock the rapid wind lever. 2. Compose your picture. 3. Set the proper shutter speed. 4. Select the f stop you want by setting the diaphragm ring. 5. Focus. 6. Trip the shutter. 7. Load the film by opening the back, inserting the cassette, pulling out the film leader, and inserting it into the take-up spool. Turn the rapid wind lever to engage sprockets and close the back. 8. To wind film, turn rewind knob clockwise slightly, then use rapid wind lever. Cock shutter and trip. Set exposure counter to 0 and trip again. Always cock rapid wind lever completely. 9. To rewind film, unfold crank, depress release button, and turn crank. Stop when tension lessens. Open back, pull rewind knob, and remove cassette.
