Brand: HITACHI
Category: TV
Document Type: Manual
Language: EN
Manual for 35TX59K, 35TX50B
Uploaded: Nov. 21, 2025, 7:01 p.m.
Warranty Information
Contact Hitachi for in-warranty service, operation, or technical assistance.
- Power: Press the POWER button to turn the TV on or off.
- Volume: Use the VOLUME up (▲) or down (▼) buttons to adjust the sound level.
- Mute: Press the MUTE button to temporarily turn off the sound. Press again or VOLUME UP to restore.
- Channel Selection: Use the CHANNEL buttons to select channels. For channels 1-9, enter '0' first. For channels 100+, use the '100' button. Channel up/down arrows also work.
- AVX (Input Selection): The AVX button cycles through antenna signal and three video input jacks (VIDEO 1, VIDEO 2, VIDEO 3).
- Recall: The RECALL button displays information like channel, stereo status, on/off timer, and time. It can also clear on-screen displays.
- Menu and Setup: Press MENU to access on-screen display features. Use CURSOR buttons to navigate and ENTER to select or adjust functions like Closed Captioning, Initial Setting, Picture, Sound, and Timer Set.
- Antenna Input (35TX50B/35TX59K): The ANT button switches between VHF/UHF and AUX antenna inputs. The screen display color indicates the selected input (Green for VHF/UHF, Yellow for AUX).
Troubleshooting and error codes
| SYMPTOMS | CHECK THESE ITEMS AND TRY THESE ADJUSTMENTS | ||||||||||||||
| Be sure external connection is correct | Be sure power cord is plugged in | Be sure TV is switched "ON" | Try another channel (station trouble) | Check outside antenna | Check antenna connections (back of TV) | Check antenna for broken lead-in wire | Check for local interference | Adjust Contrast control | Adjust Brightness control | Adjust Color control | Adjust Tint control | Adjust Volume control | Try another antenna | ||
| No picture, no sound | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Sound OK, picture poor | • | • | • | • | • | • | • | ||||||||
| Picture OK, sound poor | • | ||||||||||||||
| Picture blurred | • | • | • | • | • | ||||||||||
| Lines or streaks in picture | • | • | • | • | • | ||||||||||
| Poor reception on some channels | • | • | • | • | • | ||||||||||
| Picture rolls vertically | |||||||||||||||
| No color | • | • | • | • | • | • | • | ||||||||
| Poor color | • | • | • | • | • | • | • | ||||||||
