The Hitachi Virtual Storage Platform G130 is a storage system comprised of a controller chassis and drive trays. It supports SFF and LFF SAS disk drives, offering modular configurations, high reliability, strong performance, and expandable storage capacity. The system includes dual controllers, cache flash memory, and battery backup modules. It supports 16-Gbps FC host interfaces. System configurations vary in the number of drive trays and SAS drives supported.

Troubleshooting and error codes

Item	Specification	Details
WARNING LED	Amber Blink	Failure occurred. Requires maintenance. When the SIM is confirmed, the LED pattern indicates the failure and requires attention. Note: When System Option Mode 1097 is set to ON, the WARNING LED does not blink, even if the following failure service information messages (SIM) are issued: 452xxx, 462xxx, 3077xx, 4100xx, and 410100. LED might turn off during user maintenance.
ALARM LED	Red ON	Processor failure (system might be down). For assistance, contact customer support: https://support.hitachivantara.com/en_us/contact-us.html.
