Manual for PXR
Uploaded: Nov. 21, 2025, 7:32 p.m.
Manual Publish Date: 2008-12-01
Warranty Information
Refer to the appropriate sections within the manual for specific warranty information.
This manual provides comprehensive information on the HITACHI PXR printer, covering its introduction, safety precautions, structure, installation, and maintenance. Key operational aspects include setting up the maintenance mode, system environment, and performing various adjustments and operational checkouts. It details procedures for excitation adjustment, charging voltage confirmation, phase margin testing, and auto phase gain adjustment. The manual also covers level sensor confirmation, heating unit confirmation, and solenoid valve/pump testing. Procedures for downloading software options and calibrating the viscometer are also included, along with ink concentration control and system reset functions. Backup procedures, unit information, and handling of specific error warnings are also addressed.
Troubleshooting and error codes
| Fault Code | Description | Page |
|---|---|---|
| 7.1 | Addition of following troubleshooting | 7-2 |
| 7.5.9 | "7.5.9 Freeze of display" | 7-49 |
| 7.6.5 | "7.6.5 Failure of adjustment of excitation voltage" | 7-54 |
| 7.6.6 | "7.6.6 & 7.6.7 System error (xxx)" | 7-55 |
| 7.6.7 | ||
| 7.2 | Faults - Ink-stop type | 7-3 |
| 7.3 | Faults - Print-stop type | 7-22 |
| 7.4 | Warning conditions (printing continuously performed) | 7-32 |
| 7.5 | Faults - No on-screen indications | 7-42 |
| 7.6 | Miscellaneous | 7-51 |
