Manual for VM-6400A/VM-7400A
Uploaded: Aug. 10, 2025, 12:52 a.m.
Warranty Information
Warranty terms are stated on the warranty card or operating guide.
- Inserting/Removing Cassettes: Connect power source, press STOP/EJECT to open the cassette holder, slide cassette in with window facing you and arrow pointing to the holder. Push until latched. To remove, press STOP/EJECT.
- Camera Recording: Set CAM/OFF/VIDEO to CAM. Press REC/PAUSE to start recording. "REC" appears in viewfinder. Press again to pause. "-" appears.
- Instant Review: In record/pause, tap REW/REVIEW to play back the last few seconds in reverse then forward. Returns to record/pause.
- Playback: Set CAM/OFF/VIDEO to VIDEO. Use REW/REVIEW to find start point. Press PLAY. Adjust TRACKING if needed. Press STOP/EJECT when finished.
- Date/Time Setting: Power on, set CAM/OFF/VIDEO to CAM. Press DATE/TIME. Select month, date, year, hour, minute, AM/PM using F.FWD/REW/REVIEW and STOP/EJECT. Press DATE/TIME to finalize.
- Title Recording: Set CAM/OFF/VIDEO to CAM or VIDEO. Press TITLE. Use SHIFT to move cursor, -/+ to select characters. Press TITLE to store.
- Viewing on TV: Connect camcorder to TV using audio/video cable or RF converter. Set CAM/OFF/VIDEO to VIDEO, insert tape, press PLAY.
Troubleshooting and error codes
| Symptom | Check Point & Correction |
|---|---|
| Cassette holder cannot be opened when you press "STOP/EJECT". |
* Connect the power source. * Load cassette in direction indicated by arrow on cassette. * Cassette window must be toward outside. |
| Cassette cannot be inserted into cassette compartment. | (See above) |
| Picture does not appear in the viewfinder. |
* Remove the lens cap. * Set "CAM/OFF/VIDEO" to "CAM" position. |
| The camcorder can not go into the recording mode, even when "REC/PAUSE" is pressed. |
* The cassette has had the erase prevention tab removed. Stick a piece of cellophane tape over the erase prevention hole or select a different cassette. * Set "CAM/OFF/VIDEO" to "CAM" position. |
| Picture is out of focus. | Auto-focus does not operate if the wide angle or telephoto lens is attached. |
| Auto-focus does not operate. | (See above) |
| The "▶" indication in the electronic viewfinder flashes to indicate battery is discharged. | * Try another battery or charge the battery. |
| NO OPERATION IS ACCEPTED | * Remove the power source, and after about one minute push the reset switch gently using a toothpick, etc. until you feel a click. Since this erases the date, time and other customer preferred features, reset them again. |
| "PLAY" cannot be engaged. |
* Set "CAM/OFF/VIDEO" to "VIDEO" position. * Set the television to the camcorder channel (3 or 4) depending upon the selected channel on the RF channel select switch of RF converter unit. |
| No picture appears on television screen when "PLAY" is pressed. (TV is connected to the camcorder by using RF converter unit.) |
(See above) |
| Interference on playback picture. |
* Adjust the tracking using "TRACKING" control (power zoom switch). * When you see the playback picture on your TV, adjust fine tuning knob on television set to obtain best picture. * The pre-recorded tape is EP or LP recording. This camcorder is for use in SP recording only. |
| Picture bends at the top of TV screen. |
* TV receiver is of older type. It needs to be modified to work properly with camcorder * Tape is damaged. Try another cassette. |
| Color of your TV screen is too bright, too faint or change. | * TV set has VIR circuit. Turn it off during playback. |
