Brand: HITACHI
Category: Camcorder
Document Type: Manual
Language: EN
Manual for DZ-MV350A DZ-MV380A
Uploaded: Aug. 10, 2025, 12:51 a.m.
Manual Publish Date: 2003
Warranty Information
None
\n
- \n
- Setups: Learn how to set up the DVD video camera/recorder, battery, and set the date/time. \n
- Basic Techniques: Covers fundamental operations like recording movies, still images, external input, and playback. \n
- Advanced Techniques: Explores advanced settings for more sophisticated usage. \n
- Disc Navigation: Details editing with Disc Navigation, finalizing DVD-R discs, and initializing DVD-RAM discs. \n
- Installing Software: Guide to the provided CD-ROM contents and software installation. \n
- Subsidiary Information: Includes details on optional products, cleaning, and troubleshooting. \n
Troubleshooting and error codes
| Symptom | Cause and Correction | Reference page |
|---|---|---|
| Recognition of disc is not complete | Is disc dirty? Use soft, dry cloth to clean it. |
76 |
| Pressing the playback button will not start playback. | Has the image been recorded by devices other than this DVD video camera/recorder? Playback of image recorded on devices other than this DVD video camera/recorder may be impossible on this DVD video camera/recorder. |
128 |
| Has scene been edited on a device other than this DVD video camera/recorder? If a scene recorded on this DVD video camera/recorder is edited on a device other than this DVD video camera/recorder, playback may not be possible on this DVD video camera/recorder. |
||
| No playback picture appears on TV screen. | Is TV input selector set correctly? Some TVs have multiple video input jacks. Check whether the correct input was selected on TV to match the connected jacks. If the DVD video camera/recorder is connected to VCR, set its input selector to "external input (LINE)”. |
73 |
| Is the DVD video camera/recorder connected to TV correctly? Check the connections. |
72 | |
| Playback picture is momentarily interrupted. | Is disc scratched or does dirt or fingerprint adhere to it? Clean the disc. |
76 |
| Poor playback picture | Was the image input from analog VCR (VHS, 8 mm) and recorded? The problem may be improved if a VCR equipped with TBC circuit is used for playback. |
— |
| Playback picture is greatly distorted. | Was recording of external input made with “Frame” specified? Specify "Field” for “PHOTO Input” in record mode settings. |
88 |
| No sound | Is the TV volume control set correctly? Adjust TV volume control, and be sure to adjust the volume on TV. |
73 |
| Disc Navigation thumbnails do not appear. | Was the image recorded from AV input/output jack with interference? Record image with no noise or disturbance. |
— |
