RWT350AW Operation Summary

Temperature Wash / Rinse (1): Select water temperature for wash and rinse.
Load Size (Water Level) (2): Set water level (Super, Large, Medium, Small, Extra Small) before wash or in pause mode. Can manually replenish water during Soak, Wash, or Rinse.
Cycle Select (3): Choose from 7 cycles: Normal, Whites, Colors, Heavy, Delicate, Quick, Spin only.
Start/Pause Button (4): Press to start wash, pause, or resume. Auto-off after 5 minutes in pause mode.
Process Status (5): Shows current cycle status.
Extra Rinse (6): Press to activate/deactivate for an additional rinse. Automatically added to Whites Cycle.

Cycle Select (1): Choose from 4 cycles: Normal, Heavy, Delicate, Quick, each with specific processes, load sizes, and temperatures.
Start/Pause Button (2): Press to start, pause, or resume wash. Auto-off after 5 minutes in pause mode.
On/Off (3): Press to turn power on or off.

Phenomenan	The reason	How to settle
No water filling or filling slowly (the suitable water level doesn't research about 40 minutes).	The top lid is not closed.	Open and close the top lid once.
The draining does not work, or the speed of draining is too slow (the suitable water level doesn't research about 8 minutes).	The top lid is not closed.	Open and close the top lid once.
The machine stops running In washing, rinsing or spinning.	The top lid is not closed.	Close the top lid.
The spinning can not work (after amending twice automatically)	Are the laundries put slantingly?	Level the machine in right position.
	Is the machine slanting?	Open and close the top lid once.
The machine does not act. (Indicators are off.)	Is the power off?	Use it when the power is on.
	Does the power cord loose?	Insert the power plug tightly.

Phenomena	Explanation
Press the knob to select "Spin", but it doesn't work.	The program is setting the drain time. Some time is needed before it starts spinning.
There may be some water flowing out of the drain hose in the first use of the machine.	It is the water remained in the factory inspection of performance.
