Brand: Haier
Category: Washing Machines
Document Type: Manual
Language: EN
Manual for HWM60-10
Uploaded: Nov. 21, 2025, 7:36 p.m.
Warranty Information
No specific warranty period is mentioned in this manual.
Before Using
Safety Precautions: Ensure proper electrical connection with earthing. Avoid bending power cords. Do not place the machine in damp areas or use hot water above 50°C. Avoid washing waterproof items. Do not allow children to play with or operate the machine. Remove foreign objects from pockets before washing. Ensure the water tap is open and the inlet hose is connected.
Installation and Adjustment:
Install the lint filter and bottom plate securely. Adjust the feet to ensure the machine is level to prevent unstable running.
How to Use the Drain Hose:
Change the direction of the drain hose by loosening screws and repositioning. Ensure the drain hose height is less than 10cm for smooth drainage. Do not trample or press the hose. If an extra hose is needed, ensure it meets specifications.
Install the Water Inlet Hose:
Use the provided hose set with new washers. Connect to the faucet and the machine's inlet valve. Ensure connections are stable and leak-free. Close the water tap before disconnecting.
Preparation Before Washing:
Connect the water inlet hose, open the tap, ensure earthing, and plug in. Put down the drain hose. Check laundries for special requirements, empty pockets, fasten buttons/zippers, and divide by colorfastness. Do not overload the machine. Turn items prone to linting inside out.
Put in the Laundries:
Do not exceed the rated capacity of 5.0kg. Consider the thickness and size of clothes. For small loads (less than 0.5kg), do not select "High" water level to avoid splashing.
Put in the Detergent:
For direct dissolution, fill to "Low" water level, add detergent, run for 30 seconds, then add laundries. For instant dissolving, use warm water. Use appropriate detergent quantities based on load and water level. Avoid high-sudsing detergents.
Use the Operation Buttons:
Program/Reservation: Select programs like Standard, Jeans, Gentle, Quick Wash, Wash, or Spin. Press and hold to set a reservation. Water Level: Select the appropriate water level. Start/Pause: Starts or pauses the cycle. Power On/Off: Connects or cuts off power supply. The machine has an auto shut-off feature if idle for over 10 minutes.
Operating Procedure:
1. Press "Power On/Off". 2. Select program using "Program/Reservation". 3. Select water level using "Water Level". 4. Optionally, set reservation time. 5. Press "Start/Pause". 6. Close the top lid.
Finish Washing:
The machine cuts off power automatically.
Disposal After Washing:
Clean the lint filter and foreign materials. Pull off the power plug before cleaning. Clean the lint filter by detaching, cleaning, and reassembling. Clean the water inlet valve filter every two months. Wipe the cabinet with a damp cloth. Close the water faucet, drain completely, unplug, hang cords, and wipe dry. Leave the lid open for about an hour.
Troubleshooting and error codes
| Phenomena | The reason | How to settle |
|---|---|---|
| Buzzing upon reservation starts, Nixie tube indicates "E0" | The top lid is not closed | Close the top lid |
| No or slow drain, nixie tube indicates "E1", buzzing. | Is the drain hose put down? Is the drain hose blocked by foreign material? |
Put down the drain hose. Open and close the top lid once. Clean the foreign material. Open and close the top lid once. |
| Running pauses during spin, nixie tube indicates "E2", buzzing | The top cover leaves open | Close the top lid |
| Safety switch actuates, not spin, (after self-correction twice), nixie tube displays "E3", buzzing | Are the laundries put slantingly? Is the machine slanting? |
Re-order the laundries. Close the top lid. Level the machine in right position. Open and close the top lid once. |
| No or slow water filling (not reaching the levelin 15 min), nixie tube indicates "E4", buzzing | The water tap is not open The water inlet valve is blocked The water pressure is too low and the current is too small |
Open the water tap. Push the "Start/Pause" button. Clean the water inlet valve. Push the "Start/Pause" button. Wait for the normal water pressure before use. |
| The machine does not act | Not wash: Is there power failure? Is the power plug loose? Does the water level arrive at the set water level? |
Use it when the power is on. Insert the power plug tightly. Affusion to the set water level. |
| Not spin: Is the power plug loose? Is the top lid closed? Are the laundries put orderly? |
Insert the power plug tightly. Close the top lid Put the laundries orderly. |
|
| There's abnormal sound inside the machine. | Is the machine slanting? Is there metal material inside the washing machine? Are the laundries slanting in spinning? |
Level the machine properly. Fasten the buttons and zipper Reorder the laundries. Close the top lid. |
| No water filling | Is the power plug loose? If the water faucet is turned on? If Power On/Off and Start/Pause are pressed? |
Insert the plug firmly Turn on the water faucet Press Power On/Off and Start/Pause |
| The machine does not act. (the indicators are off.) | Is there power failure? Is the power plug loose? |
Use it when the power is on. Insert the power plug tightly. |
