WELCOME

Thanks for buying this 26"/32"/40" HD Ready Digital LED LCD TV. This guide will help you to set up and begin using your TV.

Firstly, check the contents of your box with the parts checklist below:

  • 26"/32"/40" HD Ready Digital LED LCD TV
  • Remote control
  • AAA battery x2
  • Instruction Manual
  • Warranty
  • TV Stand
  • 5x Screws for TV stand
  • Component adapter, Component audio adapter, SCART adapter
  • Cover bottom

Now you can get started!

IMPORTANT INFORMATION

READ ALL INSTRUCTIONS BEFORE USE AND KEEP FOR FUTURE REFERENCE.

Getting Started

This section guides you through the initial setup and basic operation of your TV.

Setting up

  • LOCATION: Place your TV near a power socket and aerial connection.
  • CONNECTION: Connect your aerial to the ANTENNA IN socket.
  • SWITCHING YOUR TV ON: Press the POWER button on the TV or remote control. Select your language and follow on-screen prompts.
  • TUNING YOUR TV: Access the tuning menu via the MENU button to perform Auto Search or Digital/Analog Manual Search.
  • SWITCHING TO AN EXTERNAL SOURCE OTHER THAN TV: Use the SOURCE button to select input devices like DVD players or PCs.

USING YOUR TV

  • How to select the TV program: Use the number keypad or P+/P- buttons on the remote.
  • How to adjust volume: Use the V+/V- buttons on the remote or the TV.
  • CH.LIST function: Access and manage your channel list.

ADJUSTING PICTURE SETTINGS

Navigate to the Picture menu to adjust Contrast, Brightness, Colour, Sharpness, Tint, Mode, Colour Temperature, Noise Reduction, and Reset settings.

ADJUSTING SOUND SETTINGS

Navigate to the Sound menu to adjust Balance, Mode, AVL, SRS TS XT, Digital Audio Output, and Equalizer settings.

FUNCTION SETTINGS

Access Function settings to configure Language, Subtitle Language, Display Mode, Blue Screen, Recorder, DCR, OSD Time Out, OSD Transparency, and Reset.

TIME SETTINGS

Set the Clock, Date, Off Time, On Time, Sleep Timer, and Time Zone.

LOCK MENU SETTING

Control tuner, program, source volume, etc., using the Lock Menu. Change password, set Child Lock, Tuning Lock, Source Set, Channel No, Source Lock, Max Volume, Initial Volume, and Parental Lock.

VIDEOTEXT FUNCTIONS

Access Videotext for information and subtitles. Use colored buttons, number keys, and P+/P- to navigate pages.

USB MODE

Connect USB devices to play photos, music, and movies. Supports FAT32 format.

RECORDING

Record DTV programs to a USB storage medium.

TIMESHIFT

Pause and rewind live TV in Digital mode.

Troubleshooting and error codes

Problem Possible Cause Solution
No Picture, No Sound The power plug is not properly connected. An adequate power source is not being used. There might be a power failure. Check if the TV power plug is properly connected. Ensure you are using an adequate power source. Check for any power outages.
No Picture Incorrect signals are being input. The signal source may need to be changed. The TV may need to be restarted after a power interruption. Check if the correct signals are being input. Change the signal source via the remote control. Turn off and then on the TV after a power interruption.
No Sound MUTE is activated. The volume might be too low. The audio output might not be correctly set. Press the MUTE button to deactivate it. Press the VOL+ button to increase the volume. Check the audio output settings. Consult the manual for audio setting adjustments.
Poor Sound The audio playback may not be correctly set. Check if the audio playback is correctly set. Consult the manual for audio setting adjustments.
No Picture on Some Channels The correct program may not be selected. The antenna may need to be re-aligned. Check if the correct program is selected. Re-align the antenna.
Black and White Reception on Some Channels Check the picture and sound systems. Refer to the Color Adjustment section in the manual. Check the picture and sound systems. Refer to the Color Adjustment section in the manual.
Picture Disturbances on Some or All Channels The antenna may not be properly connected. The antenna's condition might be poor. The channel may require fine-tuning. Check if the antenna is properly connected. Check the antenna's condition. Fine-tune the channel.
TV Set Does Not Function The TV set may need to be disconnected from the power supply for 10 seconds and then reconnected. If the problem persists, contact authorized customer service for technical support. Disconnect the TV set from the power supply for 10 seconds, then reconnect. If the problem persists, contact authorized customer service for technical support.
