Manual for HYC-260

Manual for HYC-260

Brand: Haier

Category: Refrigerators

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 6:16 p.m.

Warranty Information

No warranty information is explicitly provided in the extracted pages.

Initial Power-on:

  1. Connect the power line to a dedicated socket, ensuring correct voltage and frequency.
  2. Turn on the battery charging switch. An audible alarm may sound; press the buzzer to stop it. The alarm will cease once the sensor temperature reaches 5℃±3℃.
  3. The refrigerator is pre-set to 2~8℃ and requires no manual temperature adjustment.
  4. Allow several hours for the temperature to stabilize, then verify it matches the set point.
  5. Turn on the interior light switch to ensure proper operation.
  6. Once all functional inspections are passed, load products in batches.

Operation after Power Outage:

  • Control parameters are stored even during an outage. The refrigerator will resume operation at set parameters once power is restored.
  • If the unit shuts off, wait 5 minutes before powering it up again.
  • For long-term shutdown, turn off the power and battery switches, then unplug the unit.
  • If decommissioning, remove the door and leave shelves in place. Ensure children cannot access the unit.

Troubleshooting and error codes

Alarm Type Possible Cause Solution
High Temperature Alarm Door opened for too long Close the door immediately.
Ambient temperature too high Ensure the ambient temperature is within the operating range (16-32℃).
Compressor failure Contact after-sales service.
Low Temperature Alarm Door opened for too long Close the door immediately.
Ambient temperature too low Ensure the ambient temperature is within the operating range (16-32℃).
Temperature sensor failure Contact after-sales service.
Sensor Error Alarm Temperature sensor failure Contact after-sales service.
Power Failure Alarm Power outage Check the power supply. If the unit is powered by battery, it will continue to operate.
Low Battery Power Alarm Battery is low Ensure the battery is charged.
Door Ajar Alarm Door not closed properly Close the door firmly.
