- Initial powering on: Power indicator illuminates, potential alarm for high freezer temperature that can be cancelled by pressing any key.
- Fridge storage temperature setup: Adjust temperature using the knob (Holiday, Moderate, Super Cool).
- Freezer storage temperature setup: Adjust temperature using the knob (Weak, Moderate, Super Freeze).
- Super cooling: For fresh food, activates automatically and deactivates when desired temperature is reached.
- Super freezing: For large amounts of food, activates automatically and deactivates after 24 hours.
- Holiday function: Activates at a higher temperature for the fridge compartment.
- Display control: Screen turns off after 1 minute of inactivity, lit by opening door or pressing key.
- Door open alarming: Alarm sounds and indicator flashes if door is open for more than 3 minutes.
- Over temperature alarm: Freezer compartment temperature rise triggers alarm.
- Turning off compartments: Fridge or freezer compartments can be turned off individually.
- Turning off the refrigerator: Stops operation but is not equivalent to turning off power.
Troubleshooting and error codes
| Malfunction description | Sign | Display | Display position | Sensor location |
|---|---|---|---|---|
| Malfunction of the ambient temperature sensor | H SNR | F2 | Display panel | The ambient temperature sensor is located on the display panel |
| Malfunction of the fridge storage temperature sensor | R SNR | F3 | Display panel | The fridge storage temperature sensor is located on the right side of the fridge storage compartment |
| Malfunction of the freezer storage temperature sensor | F SNR | F4 | Display panel | The freezer storage temperature sensor is located on the left side of the freezing air-duct cover |
| Malfunction of the defrosting temperature sensor | D SNR | F6 | Display panel | The defrosting temperature sensor is located on the fin evaporator |
| Malfunction of communication between the display panel and the power board | / | E0 | Display panel | / |
| Malfunction of the fan | / | E1 | Display panel | / |
