Manual for HDHP80E1

Name: Manual for HDHP80E1
Brand: Haier
Availability: InStock

Brand: Haier

Category: Dryers

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 8:43 p.m.

Warranty Information

Refer to the Warranty Card supplied with the product for warranty details.

1. Prepare the Dryer: Connect to power, ensure water tank and filters are clean and installed. 2. Prepare Laundry: Sort by fabric, empty pockets, check care labels, close zippers, and unfold large items. 3. Load Dryer: Place laundry evenly, do not overload, then switch on the dryer. 4. Select Program: Use the program knob to choose from 16 available programs. The display shows remaining time. 5. Start Cycle: Touch the Start/Pause button to begin. 6. Optional Settings: Use buttons like Anti-Crease or Dry Level for customized drying. 7. End of Cycle: The dryer will automatically turn off. Remove laundry promptly.

Troubleshooting and error codes

PROBLEM	CAUSES	SOLUTION
Tumble dryer fails to operate.	• Poor connection to the power supply. • Power failure. • No drying program is set. • Device has not been switched on. • The water tank is full. • The door is not closed properly.	• Check connection to the power supply. • Check the power supply. • Set a drying program. • Switch the device on. • Empty the water tank. • Close the door properly.
Tumble dryer fails to operate and the display shows END.	• The laundry has reached the condition defined by the program. • There is no laundry in the drum.	• Check if the program setting is appropriate. • Check if there is laundry in the drum.
Drying time is too long and the results are not satisfactory.	• The program setting is not correct. • The filter is clogged. • The evaporator is blocked. • The tumble dryer is overloaded. • The laundry is too wet. • The vent duct is blocked.	• Make sure the program is set correctly. • Clean the filter screen. • Clean the evaporator. • Reduce the amount of laundry. • Spin the laundry properly before drying. • Check the vent duct and unblock it.
Remaining time on the display stops or skips.	The remaining time will be adjusted continuously based upon the following factors: • Type of laundry. • Loaded amount. • Moisture degree of the laundry. • Ambient temperature.	The automatic adjustment is a normal operation.
