Brand: Haier
Category: Dishwashers
Document Type: Manual
Language: EN
Manual for HDW13V1
Uploaded: Nov. 21, 2025, 9:12 p.m.
Warranty Information
None
Loading the Baskets:
- Ensure delicate items are dishwasher-safe.
- Do not put items made of wood, horn, aluminum, pewter, or copper.
- Avoid items that absorb water (sponges, cloths).
- Place hollow items (cups, pans) opening down.
- Mix cutlery to prevent nesting.
- Ensure spray arms can move freely.
- Place heavily soiled items in the bottom basket.
Starting a Programme:
- Close the door.
- Press ON/OFF button.
- Select program and observe indicator.
- Optionally select delay start.
- Press START/PAUSE to begin.
Care and Cleaning:
- Regularly clean filters and spray arms.
- Disassemble filters by turning and unplugging.
- Clean with water.
- Assemble filters correctly.
- Clean spray arms by removing and flushing.
- Clean exterior with a damp cloth and neutral detergent.
Troubleshooting and error codes
| Problem | Possible cause | Possible solution |
|---|---|---|
| The programme does not start. | Appliance door is open. | Close the appliance door. |
| Delay start is set. | Refer to displayed time. | |
| Mains plug is not connected in the mains socket. | Connect the mains plug. | |
| Fuse in the house circuit is damaged. | Replace the fuse. | |
| Rinse Aid Indicator is lighted. | Rinse aid dispenser is empty. | Refill Rinse aid until full |
| Refill of rinse aid was not confirmed. | Press and hold the START/PAUSE button for 3 sec after each refill. | |
| Acoustic alarm, display shows ALARMCODE A10 The appliance does not fill with water. | Water tap is closed. | • Open the water tap. Note: Whenever Error 'A10' is solved switch off the appliance and restart the programm. |
| Water inlet hose has a kink or a bend. | Make sure that the position of the hose is correct. | |
| In case of aqua-stop system: water protection is triggered; the marker (C) is red. | The hose must be replaced. | |
| Filter in the water inlet hose is clogged. | Clean the filter at the inlet hose connections at tap and the rear of the appliance. | |
| Water inlet is clogged. | Check water flow from tap. | |
| Water pressure is too low. | Contact your local water authority. | |
| Acoustic alarm, display shows ALARMCODE A20 The appliance does not drain sufficiently. | Filters are clogged. | • Scoop out as much water as possible. • Clean filters. • Continue programme by pressing the START/PAUSE button. |
| The drainage is blocked. | • Scoop out as much water as possible. • Make sure that drain water-connection and piping is correct and not blocked. • Continue programme by pressing the START/PAUSE button. |
|
| Acoustic alarm, display shows ALARMCODE F30 Leak: The drain pump runs permanently! | Anti-flood device is on: • There are water leakages in the appliance. • The water inlet valve is open and blocked. • The drainage is blocked. |
1 Close the water tap. 2 Disconnect appliance from power supply. 3 Contact Service. |
| All other Alarmcodes: | 1. Note Alarmcode 2. Contact Service ; refer to CUSTOMER SERVICE |
|
| The dishes are not clean. | Filters are clogged. | Clean the filters. |
| Filters are not correctly assembled and installed. | Make sure that the filters are correctly assembled and installed. | |
| Spray arms are clogged. | Remove remaining food remnants with a thin pointed object. | |
| Programme was not applicable for the type of load and food remnants. | Make sure that the programme is applicable for the type of load and food remnants. | |
| Incorrect position of the items in the baskets.Water could not wash all items. | Make sure that the position of the items in the baskets is correct and that the water can easily wash all items. | |
| Spray arms could not turn freely. | Make sure that the position of the items in the baskets is correct and does not cause the blockage of the spray arms. | |
| No detergent or insufficient quantity of detergent in the detergent dispenser. | Make sure that you add the correct quantity detergent in the dispenser before you start a programme. | |
| The wash cycle was interrupted by a long break. | Do not open the door or cut power supply during the wash cycle. | |
| Whitish streaks, stains or bluish layers on glasses and dishes. | Released quantity of rinse aid is too much. | Decrease the released quantity of rinse aid. Refer to section DIFFERENT SETTINGS FOR RINSE AID. |
| Quantity of detergent was too much. | Make sure that you add the correct quantity of detergent in the dispenser before you start a programme. | |
| Multitab detergent tablets used with a short programme might not fully dissolve. | Select a longer programme when using Multitab detergent tablets | |
| Dry water drop stains on glasses and dishes. | Rinse aid dosage is too low. | Increase the released quantity of rinse aid. Refer to section DIFFERENT SETTINGS FOR RINSE AID. |
| Quality of rinse aid or Multitab. | Cleaning product too old; change the product. | |
| The dishes are wet. | • Programme had no drying phase. • Programme had a low temperature drying phase. |
Open the door slightly and leave it ajar (about 100 mm) to help the drying process. |
| The dishes are wet and matte. | Rinse aid dispenser is empty. | Refill rinse aid into the dispenser and reset the rinse aid indicator. |
| Quality of rinse aid or Multitab. | Cleaning product too old; change the product. |
