Manual for DW15-PFE S

Manual for DW15-PFE S

Brand: Haier

Category: Dishwashers

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 7:14 p.m.

  • Installation: Proper positioning, leveling, and connections for water and electricity are crucial for safe and efficient operation.
  • Loading: Arrange dishes and cutlery in the upper and lower racks, ensuring spray arms are not blocked. Use the silverware basket for utensils.
  • Detergent & Rinse Aid: Fill the detergent dispenser according to the program and top up rinse aid as indicated by the low rinse aid light.
  • Programme Selection: Choose the appropriate wash program based on the type and amount of crockery and food residue.
  • Starting the Wash: Turn on the tap, press the ON-OFF button, select the program using the program button, and then press the start button.
  • End of Programme: The dishwasher will beep, and the time-remaining indicator will show 0:00. Open the door, turn off the tap, and remove dishes once cooled.
  • Maintenance: Regularly clean filters, spray arms, and check for deposits to ensure optimal performance and longevity.

Troubleshooting and error codes

Problems... ...when the appliance is switched on
Appliance does not start up
  • Fault with fuse in mains electricity supply.
  • Plug not inserted in wall socket.
  • Appliance door not closed properly.
  • Programme button has not been pressed.
  • Water tap not turned on.
  • Blocked strainer in water intake hose.
...with the appliance itself Error display on the time-remaining indicator
When the time-remaining indicator " 22" is “do or”. Have you checked whether:
  • the door is closed properly.
When the time-remaining indicator " 22" is “Er 02". Have you checked whether:
  • the water is turned on and the hose is connected properly;
  • the water supply to the house is on and has sufficient pressure;
  • the water supply hose is crimped or bent;
  • the filter for the water supply hose is clogged.
  • the drain hose is too low.
When the time-remaining indicator " 22" is "E- 03". Have you checked whether:
  • the drain hose is crimped or bent.
  • the drain hose is too high.
When the time-remaining indicator " 22" is “Ег 06”. Have you checked whether:
  • the drain hose is too low.
Lower spray arm rotates with difficulty
  • Spray arm is blocked by small items or food remains.
Lid in detergent compartment cannot be closed
  • Detergent compartment has been overfilled.
  • Mechanism is clogged with remnants of detergent.
Indicator lamps do not extinguish after washing has finished
  • ON-OFF Button is still set to ON.
Remnants of detergent stuck inside dispenser
  • Compartment was damp when it was filled up with detergent. Compartment must be dry before detergent is added.
Water remains inside appliance after programme has ended
  • Blockage or kink in drainage hose.
  • Pump is jammed.
  • Filters are blocked.
  • The programme is still running. Wait for the programme to end.
...during washing Unusual amount of foam is creased
  • Normal washing up liquid has been poured into the rinse-aid container.
  • Remove any spilled rinse aid with a cloth as it could otherwise lead to excessive foaming during the next washing cycle.
Appliance stops suddenly while washing is taking place
  • Cut off electricity supply to appliance.
  • Water supply has been interrupted.
Knocking sound can be heard while washing is taking place
  • A spray arm is knocking against the dishes inside the appliance.
Rattling sound can be heard while washing is taking place
  • Crockery has not been stacked properly inside the appliance.
Knocking sound coming from inlet valves
  • This is caused by the way the water pipes have been laid and it has no effect upon the way the appliance functions. There is no remedy for this.
...with the dishes,cutlery, etc. Remnants of food are stuck to the dishes, cutlery, etc.
  • Dishwasher was not loaded properly. Jets of water could not reach all parts of the dishes, ect.
  • Too many items in the rack.
  • Items in the rack were touching each other.
  • Not enough detergent was added to dispenser.
  • Selected wash programme was not intensive enough.
  • Rotation of spray arm was obstructed by dishes, etc.
  • Nozzles in spray arm are blocked by remnants of food.
  • Filters are blocked.
  • Filters have been incorrectly fitted.
  • Waste-water pump is jammed.
Plastic items are discoloured
  • Not enough detergent was added to dispenser.
  • Detergent has insufficient bleaching properties. Use a detergent containing a chemical bleaching agent.
White stains are left on crockery, glasses have a milky appearance
  • Not enough detergent was added to dispenser compartment.
  • Amount of rinse-aid was set too low.
  • Although water is quite hard, no salt has been put in appliance.
  • Water softener was set too low.
  • Lid on salt container is not screwed tight.
  • If you used a phosphate-free detergent, try a detergent containing phosphates and compare results.
Dishes, cutlery, etc. have not been dried
  • Selected programme did not include drying function.
  • Amount of rinse-aid was set too low.
  • Items were removed from dishwasher too soon.
Glasses have a dull appearance
  • Amount of rinse-aid was set too low.
Tea stains or traces of lipstick have not been completely removed
  • Detergent does not have a sufficient bleaching effect.
  • Washing temperature was set too low.
Traces of rust on cutlery
  • Cutlery is not sufficiently rustproof.
  • Salt content in washing water is too high.
  • Lid on salt container is not screwed tight.
  • Too much salt was spilt while filling container.
Glasses become clouded and discoloured; coating cannot be wiped off
  • Unsuitable detergent was used.
  • Glasses are not dishwasher-proof.
Smears left behind on glasses and cutlery; glasses have acquired a metallic appearance
  • Amount of rinse-aid set too high.
