1. **Loading the Dishwasher:** Remove large food particles. Place items in the correct racks, ensuring they don't block spray arms. Pots and pans face down. Deep pots slanted. Silverware basket cannot be doubled. Upper rack holds delicate items and can be adjusted for height.
2. **Adding Detergent:** Open the dispenser, add detergent to the "C" compartment, and close until it clicks.
3. **Adding Rinse Aid:** Turn the "C" cap counter-clockwise, pour rinse aid, and adjust dosage with "F" adjuster (setting 3 is normal).
4. **Loading Salt:** Unscrew the salt container cap, fill with 2kg of salt (a small amount of water escaping is normal), and screw the cap back on. Refill when the "low salt" indicator is on.
5. **Selecting a Program:** Use the "D" knob to select a cycle. Refer to "Program Diagram" for details.
6. **Starting the Cycle:** Press the "A" ON-OFF button.
Troubleshooting and error codes
| Phenomenon | Possible Cause | Solution |
|---|---|---|
| Dishwasher does not work | Door not closed | Close the door |
| Door flap is not OK | Replace it | |
| Door switch is faulty | Change the door switch | |
| Cable or program controller is broken | - | |
| Power connector not in position | Connect it properly | |
| Water level cannot reach the required location | Stopcock is not turned on | Turn on the stopcock |
| Solenoid valve is not working or electrified | Measure whether solenoid valve is electrified; Change the solenoid valve | |
| Water intake velocity is too slow | User's water pressure is too slow | |
| Water level switch is not OK | Change water level switch | |
| Cable or program controller is broken | - | |
| Water cannot be drained | Drain pump is not working | - |
| Pipeline and drain pump blocked | Repair the pipeline and drain pump | |
| Drain hose is too high | - | |
| Drain pump is broken | - | |
| Heating trouble (program controller stop turning) | Socket connector not connected well | Connect it well |
| Thermo limiter is not OK | Change thermo limiter | |
| Heater is not OK | Change heater | |
| Water overflow trouble (drain pump keep on working) | Water deposited in the bottom case | - |
| Water flows out of the water overflow conduit | Bottom case is leaking | |
| Water level switch is not closed | Change the water level switch | |
| Water overflow switch is not OK | Change water overflow switch | |
| Dishwasher cannot work | Power connector is in position | - |
| Circuit between the two terminals is open | The cable or the controller board should be suspected | |
| Power switch is faulty | Replace the power switch |
