Brand: Generic
Category: Digital Camera
Document Type: Manual
Language: EN
Manual for ESP2
Uploaded: Nov. 21, 2025, 6:44 p.m.
Warranty Information
None
- Recording Quickly: Determine image composition on the LCD monitor and press the shutter release button.
- Confirming a File: Check recorded files on the LCD monitor immediately after recording or by switching to playback mode.
- Taking Pictures: Use Normal, Fine, or Economy modes for different recording priorities.
- Natural Color Images: Utilize the Auto White Balance feature.
- Close-up Shooting (Macro): Approach subjects as close as 1 cm.
- Monitoring on TV: Connect to a TV using the video cable.
- File Transfer: Transfer files to a computer using ESP2 software.
- Basic Operation: Prepare by inserting batteries and setting the date/time.
- Taking Pictures: Turn on power, set REC/PLAY switch, select image quality, compose, and press shutter.
- Flash Modes: Select Flash Off, Forced Flash, or Auto Flash.
- Self Timer: Use the Self Timer button for delayed shots.
- Viewing Files: Set REC/PLAY switch to PLAY and use U/T buttons to navigate.
- Erasing Files: Select ERASE or ERASE ALL and confirm with the Release button.
Troubleshooting and error codes
| Problem | Cause | Remedy |
|---|---|---|
| No power | The batteries are not installed properly or are depleted. The AC adaptor is not connected properly. |
Install the batteries correctly or replace with fresh batteries. Reconnect the AC adaptor. |
| Sudden loss of power | The Auto Power Off feature shuts down the camera after several minutes of inactivity. The batteries are depleted. |
Press the Release button more than one second or turn on the power again. Replace the old batteries with fresh batteries. |
| The batteries go dead quickly. | The batteries were subjected to excessively low or high temperatures. The built-in flash was used too frequently because of dark conditions or other reasons. |
Replace the batteries. — |
| The camera fails to record the picture when the Release button is pressed. | The batteries are not inserted properly (incorrect polarity) or are dead. The power is off, or the REC(ord)/PLAY switch is set to PLAY. The shutter release button is not fully pressed down. (Button was pressed only halfway down.) The internal memory is full. The Self Timer mode is selected. |
Reposition the batteries correctly or replace with fresh batteries. Slide the main switch to [Record]. Press the Release button all the way down. Delete some files to secure enough space. Press the SELF TIMER button to cancel the Self Timer mode. |
| The flash does not work or recharge. | The flash is recharging. Flash Off mode is selected. The White Balance mode or Macro mode is set. The batteries are dead. |
Wait until the flash lamp stops flashing. Press the FLASH button to change the setting. Press the flash button while pressing the button, then cancel the White Balance mode, or rotate the Macro dial to cancel the Macro mode. Replace with fresh batteries. |
| The flash discharged properly but the image is dark. | The distance to the subject exceeds approximately 3.0 meters. | Reduce the distance to the subject. |
| The picture is too bright. | The flash discharged when distance to the subject was less than 60 cm. The image is overexposed. The brightness adjustment dial is not set correctly. |
Select the Flash Off mode. Compensate the exposure with the +/- button. Turn the brightness adjustment dial to the right or to the left to adjust the brightness. |
| The image is underexposed. | The picture was taken in the Flash Off mode under dark conditions. The image is underexposed. The brightness adjustment dial is not set correctly. |
Press the FLASH button to change the setting. Compensate the exposure with the +/- button. Turn the brightness adjustment dial to the right or to the left to adjust the brightness. |
| The picture does not show natural colors. | The image conditions prevent the Automatic White Balance system from functioning properly. | Include a white or light-colored object in the subject, or use the flash or Fixed White Balance. |
| The camera fails to play back the data or display an image on the monitor. | The REC(ord)/PLAY switch is not set to PLAY. Video connection cable is not correctly connected to the video output terminal of the camera and the input terminal of the TV. |
Slide the REC(ord)/PLAY switch to PLAY. Connect the cable properly. |
| The image does not play back clearly. | A noise source, such as a motor, is close to the camera. | Place the camera where it is not close to a noise source. |
| The image on the monitor has disappeared. | This is a malfunction in the camera's internal memory. The batteries are dead. The Auto Power Off system has activated. |
Transfer important images to a computer, then erase all files. Replace the batteries with fresh batteries. Close the LCD monitor to turn off the power, then turn on the power again. Or, press the Release button more than one second. |
| The remote control (optional) is malfunctioning. | There is an obstruction in the path between the reception window of the camera and the transmission window of the remote control. The reception window on the camera or the transmission window on the remote control is dirty. The lithium battery in the remote control is dead. |
Clear the path between the camera and the remote control. Clean both windows. Replace the battery with a fresh lithium battery (CR2032). |
| The image has a vertical trail. | This condition occurs when a picture is taken of a well-lit subject. It is called a smear. | This is not a malfunction. |
| The camera buttons and switches do not function. | The batteries are dead. The camera does not function properly. |
Replace the batteries with fresh batteries. Close the LCD monitor to turn off the power. Reopen the LCD monitor and set the REC(ord)/PLAY switch to either REC or PLAY. If the camera still fails to function properly, try the following. 1. Remove and reinstall all batteries in the camera. 2. Reset the REC(ord)/PLAY switch to either REC or PLAY. |
| The date is incorrect. | The correct date and time have not been set. | Reset the time and date correctly. |
| The date cannot be displayed. | The batteries are dead. | Replace the batteries with fresh batteries and reset the date. |
| The camera fails to erase a file. | The REC(ord)/PLAY switch is not set to PLAY. | Slide the REC(ord)/PLAY switch to PLAY. |
| The camera changes to a mode other than the one selected. | The power was shut off manually or the Auto Power Off function turned off the power. | Select the mode again. |
| The Auto Power Off feature does not work. | The batteries were removed. The Auto Power Off feature is set to off. |
Select the mode again. Confirm the Auto Power Off setting. |
