GETTING STARTED

You can use either a Lithium Ion battery or an AC power adapter (5 V) to power on the camera. Battery power is convenient for capturing images or video clips while an AC adapter power is useful when transferring images to your computer.

Installing the Battery

  1. Make sure the camera power is off.
  2. Open the battery/SD Memory Card cover.
  3. Insert the battery in the correct orientation shown.
    • Tilt the battery lock lever toward the strap attachment and then insert the battery following the orientation of the arrow on the battery's label.
    • Insert the battery as far as it can go.
  4. Close the battery/SD Memory Card cover.

To remove the battery: Open the battery/SD Memory Card cover and then release the battery lock lever. After the battery is slightly ejected, pull out the battery slowly.

Using an AC Power Adapter

  1. Make sure the camera power is off.
  2. Connect one end of the AC power adapter to the DC IN 5V terminal.
  3. Connect the other end of the AC power adapter to a power outlet.

Charging the Battery

  1. Make sure the camera power is off.
  2. Slide the battery/SD Memory Card cover into the direction of the [OPEN] arrow.
  3. Insert the battery, noting correct polarity (+ and -).
  4. Slide the battery lock lever to adjust the battery.
  5. Close the battery/SD Memory Card cover firmly.
  6. Connect one end of the AC power adapter to the DC IN 5V terminal.
  7. Connect the other end of the AC power adapter to a power outlet.

Charging status indicators: Green: Charging start, Off: Charging end, Orange: Stand by, Red: Replace a new battery.

Inserting an SD Memory Card

  1. Make sure the camera is off.
  2. Slide the battery/SD Memory Card cover in the direction of the [OPEN] arrow.
  3. Insert an SD Memory Card (front side facing the camera).
  4. Close the battery/SD Memory Card cover.

To remove the SD Memory Card: Make sure the camera is off, open the cover, press lightly on the edge of the card, and it will eject.

Attaching the Strap

  1. Thread the small loop of the hand strap through the strap eyelet on the camera.
  2. Pull the large loop through the small loop until the strap is firmly secured.

Troubleshooting and error codes

Color State Description
Photography Mode Setup Mode Charge Mode PC Mode Battery
Green On AE or AF is locked with the Shutter button held half down. In standby mode. In communication to PC. (SD Memory Card is inserted.) Under charging
Red On Writing to SD Memory Card in progress. Accessing of SD Memory Card in progress In connecting to PC. (SD Memory Card is inserted.) Error
Flashing When the image is not in focus. — — Interval timer standing by
Orange On Processing images Charging of flash in progress — Disconnection (SD Memory Card is inserted.) No battery
Flashing Hardware malfunction SD Memory Card is not inserted. —
