Brand: GE
Category: Air Conditioner
Document Type: Manual
Language: EN
Manual for GE AIR 116
Uploaded: Nov. 21, 2025, 8:23 p.m.
Warranty Information
None
The manual details the operation, installation, and maintenance of the GE AIR 116 split system air conditioner. It covers features, technical specifications, system diagrams, remote controller functions, and troubleshooting. The operation summary includes cooling, heating, dry, and fan modes, along with special functions like sleep and swing control. The remote controller section explains how to use various buttons to adjust settings and modes. Installation instructions cover selecting the location, mounting the indoor unit, piping, wiring, and connecting the outdoor unit, followed by evacuation, leakage detection, and trial run checks. Maintenance includes cleaning the front panel and air filters. Finally, a malfunction analysis guide helps diagnose and resolve common issues.
Troubleshooting and error codes
| Check Items | Items to be checked. Possible failure |
|---|---|
| Is the installation firm enough? | Unit may drop, shake or emit noise. |
| Is leakage test done? | It may cause insufficient of refrigerating (heating) Capacity. |
| Is heat insulation sufficient? | Condensation or drop may occur. |
| Is drainage smooth? | Condensation or drop may occur. |
| Is power voltage the same as that listed in nameplate? | Failure or burn out of parts may occur. |
| Is installation of circuit and pipeline correct? | Failure or burn out of parts may occur. |
| Is unit grounded safely? | Leakage may occur |
| Is wire model fits relative regulation? | Failure or burn out of parts may occur. |
| Is air inlet or outlet vent of indoor and outdoor unit blocked? | It may cause insufficient of refrigerating (heating) Capacity. |
| Are the length of refrigerant pipe and the charge amount of refrigerant recorded? | Cannot handle the charging amount of refrigerant. |
