Manual for DL3750+/3850+

Quick Reference summarizes everyday printer operations. After you become familiar with the printer, use this section as a memory aid. Normal mode operation includes everyday operations, such as paper handling and font selection. The printer comes up in normal mode when turned on. Printer Operations (Normal Mode)
√ : Operation can be performed when the printer is in this state.
: Operation cannot be performed when the printer is in this state.
N/A : Does not apply.

Operation	Online	Offline	Required Response
Clear print buffer	√		Press MENU and TEAR OFF.
Eject single sheets	√	√	Press LF/FF.
Enter normal mode	N/A	N/A	Turn printer on. (Press on the power switch.)
Enter setup mode	√		Press TEAR OFF and ONLINE.
Exit to normal mode	√		Press ONLINE, then press TEAR OFF or MENU.
Form feed (forward)	√	√	Press and hold LF/FF until the operation starts.
Line feed (forward)	√	√	Press LF/FF within three seconds.
Load paper	√	√	Press LOAD.
Micro feed (backward)		√	Press ONLINE and LOAD.
Micro feed (forward)	√		Press ONLINE and LF/FF.
Place printer offline	√		Press ONLINE.
Place printer online	√		Press ONLINE.
Reset power-on defaults	√	√	Turn printer off, then on.
Resume printing after paper end	√		Press ONLINE.
Save adjusted load positions		√	Press ONLINE and MENU.
Select MENU1 or MENU2	√		Press MENU.
Start/stop/resume printing	√	√	Start: Send print command. Stop/resume: Press ONLINE.
Self-test printing	√	√	Start: Turn printer off. Press LF/FF while turning printer on. Pause/resume: Press TEAR OFF . Exit: Press ONLINE.
Tear off forms (Continuous forms only)	√	√	Press TEAR OFF. Tear off forms, then press any button to retract forms.
Unload paper to park position (Continuous forms only)	√	√	Press LOAD.
