Manual for FP-510II/FP-510
Uploaded: Nov. 21, 2025, 6:24 p.m.
- Using This Document: Read and understand the manual before use. Store it for future reference.
- Using Recycled Parts: The product incorporates recycled parts for environmental consideration.
- High Safety Usage: The product is designed for general use, not for high-risk applications where failure could lead to severe injury or death. Consult representatives for High Safety Required Use.
- Export Control: The manual contains technology subject to Japanese export laws. Transfer to foreign countries requires an applicable license.
Troubleshooting and error codes
| No. | Item | Explanation | Detail Setup Item |
|---|---|---|---|
| 1 | POWER ON STATUS | • Specifies reporting the power-on state. | ENABLE DISABLE |
| 2 | RECEIVE BUFFER | Specifies the capacity of the receive buffer. | 45BYTE 4KBYTE |
| 3 | BUSY CONDITION | • Status designation when printer turn is busy. BUFFERFULL: Turns busy when receive buffer is full. OFFLINE/BUFFERFULL: Turns busy when receive buffer is full or off-line. |
BUFFERFULL OFFLINE/ BFUUERFULL |
| 4 | RECEIVE ERROR *1 | • Specifies how to handle receive errors This item is valid only for the serial interface. |
IGNORE ?PRINT |
| 5 | AUTO LF | • Specifies automatic line feed using the CR code. • This item is valid only for the Parallel interface. |
ENABLE DISABLE |
| 6 | DSR(#6) RESET *1 | Specifies the reset operation using the DSR (#6) signal. • This item is valid only for the serial interface. |
ENABLE DISABLE |
| 7 | INIT(#25) RESET *1 | Specifies the reset operation using the INIT (#25) signal. This item is valid only for the serial interface. |
ENABLE DISABLE |
| 8 | INIT(#31) RESET *1 | Specifies reset using the INIT (#31) signal. • This item is valid only for the parallel interface. |
ENABLE DISABLE |
| 9 | COVER OPEN ERROR | Specifies how to handle a cover open error during printing. AUTO RECOVERY: When a cover is closed, Printer is recovery automaticity. RECOVERY BY CMND: When a cover is closed, Printer is recovery by command. |
AUTO RECOVERY RECOVERY BY CMND |
| 10 | BM CHECK AT POW-ON | • Specifies the adjustment of the leading edge of the paper at power-on. This item is valid only when the black mark detection unit is installed and "BM sensor installed" is set. |
ENABLE DISABLE |
| 11 | RETURN TO UP | • Returns the menu to the selection mode for setup group items. | - |
| 12 | RETURN TO SETUP MENU | • Returns to the setup mode menu. | - |
| *1 This is not displayed in the case of Bluetooth and USB interface model. | |||
