Getting Started:

\n

Charging the Battery:

\n
    \n
  1. Place the NP-50 rechargeable battery into the BC-45W battery charger.
    2. \n
  2. Plug the charger into a power outlet. The charging indicator will light.
    3. \n
  3. Charge the battery until complete, then remove it.
    4. \n
\n

Inserting the Battery:

\n
    \n
  1. Open the battery-chamber cover.
    2. \n
  2. Align the orange stripe on the battery with the orange battery latch and slide the battery into the camera, keeping the latch pressed.
    3. \n
  3. Confirm the battery is securely latched.
    4. \n
\n

Taking Pictures:

\n
    \n
  • 3D Pictures: Select the 3D mode on the mode dial. Position yourself appropriately and avoid obstructing the lenses.
    • \n
  • 2D Pictures: Select the 2D mode on the mode dial.
    • \n
\n

Viewing Pictures:

\n
    \n
  • Use the playback button to review images.
    • \n
  • Switch between 3D and 2D views using the designated button.
    • \n
\n

Troubleshooting:

\n
    \n
  • Refer to the \"Warning Messages and Displays\" section for common error messages and their solutions.
    • \n
  • For issues like \"NO CARD\", insert a memory card.
    • \n
  • For \"CARD NOT INITIALIZED\", clean the card contacts or format the card.
    • \n
\n

Troubleshooting and error codes

Warning Description Solution
(red) The battery is low. Charge the battery or insert a fully-charged spare battery.
(blinks red) The battery is exhausted. Use the flash or mount the camera on a tripod.
!& AF (displayed in red with red focus frame) The camera can not focus.
  • Use focus lock to focus on another subject at the same distance, then recompose the picture (pg. 32).
  • If the subject is poorly lit, try focusing at a distance of about 2 m (6.6ft.).
  • Use macro mode to focus when taking close-ups.
Aperture or shutter speed shown in red The subject is too bright or too dark. The picture will be over- or under-exposed. If the subject is dark, use the flash.
Lens is obstructed by a finger or other object. Remove the obstruction.
FOCUS ERROR Camera malfunction. Turn the camera off and then on again, taking care not to touch the lens. If the message persists, contact a FUJIFILM dealer.
ZOOM ERROR
LENS CONTROL ERROR
NO CARD No memory card inserted when COPY is selected in the playback menu. Insert a memory card.
CARD NOT INITIALIZED The memory card or internal memory is not formatted or the memory card was formatted in a computer or other device. Format the memory card or internal memory using the FORMAT option in the camera setup menu (pg. 82).
The memory card contacts require cleaning. Clean the contacts with a soft, dry cloth. If the message is repeated, format the memory card (pg. 82). If the message persists, replace the memory card.
PROTECTED CARD Camera malfunction. Contact a FUJIFILM dealer.
BUSY The memory card is locked. Unlock the memory card (pg. 9).
The memory card is incorrectly formatted. Use the camera to format the memory card (pg. 82).
CARD ERROR The memory card is not formatted for use in the camera. Format the memory card (pg. 82).
The memory card contacts require cleaning or the memory card is damaged. Clean the contacts with a soft, dry cloth. If the message is repeated, format the memory card (pg. 82). If the message persists, replace the memory card.
Incompatible memory card. Use a compatible memory card.
Camera malfunction. Contact a FUJIFILM dealer.
MEMORY FULL INTERNAL MEMORY IS FULL INSERT A NEW CARD The memory card or internal memory is full; pictures can not be recorded or copied. Delete pictures or insert a memory card with more free space.
WRITE ERROR Memory card error or connection error. Re-insert the memory card or turn the camera off and then on again. If the message persists, contact a FUJIFILM dealer.
Not enough memory remaining to record additional pictures. Delete pictures or insert a memory card with more free space.
READ ERROR The memory card or internal memory is not formatted. Format the memory card or internal memory (pg. 82).
The file is corrupt or was not created with the camera. The file can not be played back.
The memory card contacts require cleaning. Clean the contacts with a soft, dry cloth. If the message is repeated, format the memory card (pg. 82). If the message persists, replace the memory card.
Camera malfunction. Contact a FUJIFILM dealer.
FRAME NO. FULL The camera has run out of frame numbers (current frame number is 999-9999). Format the memory card and select RENEW for the FRAME NO. option in the set-up menu. Take a picture to reset frame numbering to 100-0001, then return to the FRAME NO. menu and select CONTINUOUS.
TOO MANY FRAMES Date for which more than 4,999 pictures exist selected in sort-by-date view. Choose a different date.
CAN NOT EXECUTE Red-eye removal can not be applied to the selected picture or movie. —
PROTECTED FRAME An attempt was made to delete or rotate a protected picture. Remove protection before deleting or rotating pictures.
NO IMAGE The source device selected in the playback COPY menu contains no pictures. Select a different source.
CAN NOT CROP An attempt was made to crop a 640 picture. These pictures can not be cropped.
CAN NOT CROP The picture selected for cropping is damaged or was not created with the camera.
DPOF FILE ERROR The DPOF print order on the current memory card contains more than 999 images. Copy the pictures to internal memory and create a new print order.
CAN NOT SET DPOF The picture can not be printed using DPOF. —
CAN NOT SET DPOF Movies can not be printed using DPOF. —
CAN NOT ROTATE The picture can not be rotated. —
CAN NOT ROTATE Movies can not be rotated. —
PRESS AND HOLD THE DISP BUTTON TO DEACTIVATE SILENT MODE An attempt was made to choose a flash mode or adjust the volume with the camera in silent mode. Exit silent mode before choosing a flash mode or adjusting the volume.
COMMUNICATION ERROR A connection error occurred while pictures were being printed or copied to a computer or other device. Confirm that the device is turned on and that the USB cable is connected.
PRINTER ERROR PRINTER ERROR RESUME? Printer out of paper or ink, or other printer error. Check printer (see printer manual for details). To resume printing, turn the printer off and then turn it back on.
CAN NOT BE PRINTED An attempt was made to print a movie, a picture not created with the camera, or a picture in a format not supported by the printer. Movies and some pictures created with other devices can not be printed. If the picture was created with the camera, check the printer manual to confirm that the printer supports the JFIF-JPEG or Exif-JPEG format. If it does not, the pictures can not be printed.
