Brand: eWON
Category: Industrial IoT Gateway
Document Type: Installation Guide
Language: EN
Installation Guide for Cosy+
Uploaded: April 20, 2026, 8:12 p.m.
Manual Publish Date: 2023-01-16
Warranty Information
The device comes with a warranty period of 36 months.
The Ewon® Cosy+ is an industrial gateway/router compatible with Talk2M cloud connectivity services. It allows for remote access to Ethernet and/or USB devices. The device features Ethernet ports for LAN and WAN, with specific configurations for different models (ETH, WiFi, 4G NA, 4G EU, 4G APAC). It supports DIN rail or wall mounting and has LED indicators for status monitoring. The device can be configured via a web interface or through tools like eBuddy and eCatcher. It is powered by an external 12-24Vdc supply and has a CR2032 battery for its real-time clock.
Key Operations:
- Powering On: Allow ~2 minutes for boot process. USR LED indicates status.
- Web Interface Access: Connect to LAN port #1 and access via browser using IP address 10.0.0.53.
- Configuration: Use eCatcher Easy Setup or the Embedded Wizard Setup.
- Reset: User Reset (Level 1) erases user files and system settings; Factory Reset (Level 2) restores default settings.
Troubleshooting and error codes
| Reset Level | Erased or Reset | Preserved |
|---|---|---|
| Impact of a reset level 1: User reset | Ewon® Cosy+ identification Custom user web site |
LAN IP address + mask Internet access User Password Language settings Modem / Wi-Fi settings Talk2M configuration Proxy configuration LAN switch configuration Gateway (USB, NAT 1:1) |
| Impact of a reset level 2: Factory reset | The Ewon® Cosy+ will be reset to a factory settings configuration. All parameters will be lost |
