Brand: EPSON
Category: Scanner
Document Type: Manual
Language: EN
Manual for DS-530 II
Uploaded: Sept. 12, 2025, 4:29 a.m.
Manual Publish Date: 2020-01-01
Warranty Information
None
Paper Protection to Reduce Damage to the Originals
This scanner prevents damage to originals by stopping scanning when a feeding error is detected, such as when stapled documents are scanned by mistake.
Notification of Dirt on the Sensor
The scanner detects dirt on the sensor and notifies you to clean it, preventing lines in scanned images and maintaining image quality.
Double-Feed Detection Feature with Selectable Stop Timing
When multiple documents are fed, the scanner stops scanning. You can choose to stop immediately or after ejecting the document.
High-Quality Scanning with Automatic Document Detection
The scanner offers automatic Color/Black & White and Color/Grayscale detection, suitable for various documents and applications. It produces high-quality grayscale images for monochrome documents with figures and tables.
Troubleshooting and error codes
| Scanner errors | ||
| Indicators | Situation | Solutions |
| !Flashing slowly | A paper jam or double feed occurred. | Open the scanner cover, and then remove jammed originals. Close the cover to release the error. Load the originals again. |
| !On | The scanner cover is opened. | Close the scanner cover. |
| ! • Flashing fast Flashing fast |
A fatal error has occurred. | Turn the power off and on again. If the error continues to occur, contact your local dealer. |
| !on On Off On |
The scanner has started in recovery mode because the firmware update failed. | Follow the steps below to try to update the firmware again. 1. Connect the computer and the scanner with a USB cable. (During recovery mode, you cannot update the firmware over a network connection.) 2. Visit your local Epson website for further instructions. |
