Troubleshooting and error codes

Error Code	Description	Possible Causes	Recommended Actions
41:3 ACTUATOR CIRCUIT	The DLCU on I/O board type 10 continuously controls the circuit to the door lock solenoid. DLCU can detect an open circuit (>50 KΩ) but not a short circuit.	Open circuit to the door lock solenoid. Open circuit in the door lock solenoid. Error or open circuit in the I/O board 10 circuits.	1. Check resistance in door lock solenoid circuit. Correct reading is approx. 6 Ω. 2. Check if error "AC" still remains in DLCU status.
41:21 CHARGE CIRCUIT	Only on Pocket washer. This error relates to I/O board type 10 on "Unloading side". The DLCU on I/O board type 10 contains an arming circuit that is charged when the door lock coil is to be activated.	The error can bee caused by overloads and/or defective components in the DLCU on I/O board type 10.	CPU reads the error message when the door is locked and unlocked and generates an error.
41:22 SET SIGNAL NO TACHO. WAIT 5 MINUTES	Only on Pocket washer. This error relates to I/O board type 10 on "Unloading side". The DLCU on I/O board type 10 counts the tacho pulses from the motor in order to guarantee that the drum is standing still before the door is opened.	Open or shorted circuit to the tacho sensor. Damaged tacho sensor or magnet. Secondary fault due to a error in the motor system.	1. Check that motor is actually running. 2. Check there is voltage from tachometer output when motor is running. 3. Check that rotation is detected in DLCU status for the I/O type 10 board.
41:23 ACTUATOR CIRCUIT	Only on Pocket washer. This error relates to I/O board type 10 on "Unloading side".	Open circuit to the door lock solenoid. Open circuit in the door lock solenoid. Error or open circuit in the I/O board 10 circuits.	1. Check resistance in door lock solenoid circuit. Correct reading is approx. 6 Ω. 2. Check if error "AC" still remains in DLCU status.
42:1 INTERNAL ERROR	I/O unit type 6, reading of internal analog values out of range.	Intermittent error in wiring to I/O type 6 unit. Internal error in I/O type 6.	1. Switch power off for 1 minute and try again. 2. If problem remains, replace defective part.
42:2 POSITION TEST	Position test is used to verify that I/O type 6 unit is correctly assembled and fixed in the expected position.	N/A	1. Check that I/O type 6 unit is assembled and fixed in correct position.
42:3 EXTRACT TEST	I/O unit type 6 is not able to read any or too low values during extraction.	N/A	1. Check that I/O unit type 6 unit is assembled and fixed in correct position. 2. Put some unbalance in drum and run motor to extraction speed in service program. Check analog input readings for I/O 6.
50:18 START NOT ALLOWED	External MIS system has denied the machine to start.	Check for reason in payment system (Program not paid, Too short time of booked session left, Machine not reserved, Start not allowed). External input for "START NOT allowed" is active.	N/A
50:20 OUT OF OPERATION	External MIS system has set machine out of operation.	N/A	1. Check for the reason in the settings for MIS system.
51:22 NO CBT COMMUNICATION	Machine connected to payment system using serial communication to machine.	Communication has been established once and then interrupted.	1. Check electrical connections between CPU and payment system. 2. If running in a network, check network cables between machine and payment system. 3. Check that payment system is operational. 4. Check that payment system and machine is configured to the same Machine adress (Config 1). 5. To reset machine to working state without repairing payment system, use Reset CBT communication in service mode. (Requires password).
52:1 CMIS COMMUNICATION ERROR	Communication between machine and CMIS computer has been interrupted.	If using ELS Common Service Tool process viewer and cable has been unplugged before processviewer has been stopped, this warning will occur. If running with ELS CMIS and communication is interrupted to PC, warning will occur.	1. If using ELS CST, reconnect, enter Processviewer and select function "Reset MIS communication". 2. If using ELS Network and CMIS: Check ELS network cable between machine and PC. Check that CMIS application is active and running normally.
52:2 DMIS COMMUNICATION ERROR	Problem in DMIS communication (between machine and external detergent dosing system).	The external dosing system has been disconnected, switched off or broken. Machine address in machine has been changed and this is also used by external dosing system.	1. Check connections, cables or network between machine and detergent dosing system. 2. Consult the supplier for external dosing system.
60:5 FATAL ERROR INVALID RUNNING MODE	The control system has an internal error during memory read.	N/A	1. Press the control knob/start button to retry. 2. If problem persists, upload new software.
60:11 FATAL ERROR EXTERNAL FLASH WRITE	The control system has an internal error during memory read.	N/A	1. Press the control knob/start button to retry. 2. If problem persists, upload new software.
60:17 FATAL ERROR INVALID OPTION	The control system has an internal error during memory read.	N/A	1. Press the control knob/start button to retry. 2. If problem persists, upload new software.
60:18 FATAL ERROR INVALID MODULE	The control system has an internal error during memory read.	N/A	1. Press the control knob/start button to retry. 2. If problem persists, upload new software.
60:28 FATAL ERROR INVALID COIN INPUT	The control system has an internal error during memory read.	N/A	1. Press the control knob/start button to retry. 2. If problem persists, upload new software.
60:29 FATAL ERROR INVALID FONT	The control system has an internal error during memory read.	N/A	1. Press the control knob/start button to retry. 2. If problem persists, upload new software.
