This manual provides detailed service information for the Electrolux T5350 tumble dryer. It covers component identification, technical data, function checks, and step-by-step procedures for replacing various parts including sensors, heating elements, motors, control panels, and door components. It also includes troubleshooting guidance and maintenance instructions to ensure the proper functioning and longevity of the appliance. Safety precautions are emphasized throughout the manual for qualified personnel.
Troubleshooting and error codes
| Error Code | Description | Possible Causes | Recommended Actions |
| 41:1 CHARGE CIRCUIT | Internal error related to door lock activation. | Overloads and/or defective components in the DLCU on I/O board type 10. | Check for overloads or defective components. Relates to I/O board type 10 on "Loading side". See also 41:21 for "Unloading side". |
| 41:2 SET SIGNAL NO TACHO. WAIT 5 MINUTES | Tacho signal issue during drum standstill. | Open/short circuit to tacho sensor, damaged tacho sensor/magnet, secondary fault in motor system. | Check motor running, voltage from tachometer output, and rotation detection in DLCU status. Relates to I/O board type 10 on "Loading side". See also 41:22 for "Unloading side". |
| 41:3 ACTUATOR CIRCUIT | Issue with the door lock solenoid circuit. | Open circuit to door lock solenoid, open circuit in solenoid, error/open circuit in I/O board 10 circuits. | Check resistance in door lock solenoid circuit (approx. 6 Ω). Check "AC" status in DLCU. Relates to I/O board type 10 on "Loading side". See also 41:23 for "Unloading side". |
| 41:21 CHARGE CIRCUIT | Internal error related to door lock activation (Pocket washer only). | Overloads and/or defective components in the DLCU on I/O board type 10. | Relates to I/O board type 10 on "Unloading side". See also 41:1 for "Loading side". |
| 41:22 SET SIGNAL NO TACHO. WAIT 5 MINUTES | Tacho signal issue during drum standstill (Pocket washer only). | Open/short circuit to tacho sensor, damaged tacho sensor/magnet, secondary fault in motor system. | Relates to I/O board type 10 on "Unloading side". See also 41:2 for "Loading side". |
| 41:23 ACTUATOR CIRCUIT | Issue with the door lock solenoid circuit (Pocket washer only). | Open circuit to door lock solenoid, open circuit in solenoid, error/open circuit in I/O board 10 circuits. | Relates to I/O board type 10 on "Unloading side". See also 41:3 for "Loading side". |
| 42:1 I/O TYPE 6 INTERNAL ERROR | Internal analog values out of range for I/O unit type 6. | Intermittent error in wiring, internal error in I/O type 6. | Switch power off for 1 minute. If problem persists, replace defective part. |
| 42:2 I/O TYPE 6 POSITION TEST | Verifies correct assembly and fixation of I/O type 6 unit. | Incorrect assembly or fixation. | Check that I/O type 6 unit is assembled and fixed in correct position. |
| 42:3 I/O TYPE 6 EXTRACT TEST | I/O unit type 6 cannot read values during extraction. | Incorrect assembly or fixation, issues with motor extraction speed. | Check unit assembly and fixation. Run motor to extraction speed and check analog input readings. |
| 51:22 NO CBT COMMUNICATION PRESS TO RETRY | No communication between machine and payment system. | Communication interrupted after initial establishment. | Check electrical connections, network cables, payment system operation, and configuration. Reset communication in service mode if necessary. |
| 52:1 CMIS COMMUNICATION ERROR | Interrupted communication between machine and CMIS computer. | ELS CST cable unplugged, ELS CMIS communication interrupted. | Reconnect ELS CST, reset MIS communication. Check ELS network cable and CMIS application. |
| 52:2 DMIS COMMUNICATION ERROR | Problem in DMIS communication with external detergent dosing system. | Dosing system disconnected, switched off, broken, or incorrect machine address. | Check connections and cables. Consult supplier for external dosing system. |
| 60:5 FATAL ERROR INVALID RUNNING MODE | Internal error during memory read. | - | Press control knob/start button to retry. If persists, upload new software. |
| 60:11 FATAL ERROR EXTERNAL FLASH WRITE | Internal error during memory read. | - | Press control knob/start button to retry. If persists, upload new software. |
| 60:17 FATAL ERROR INVALID OPTION | Internal error during memory read. | - | Press control knob/start button to retry. If persists, upload new software. |
| 60:18 FATAL ERROR INVALID MODULE | Internal error during memory read. | - | Press control knob/start button to retry. If persists, upload new software. |
| 60:28 FATAL ERROR INVALID COIN INPUT | Internal error during memory read. | - | Press control knob/start button to retry. If persists, upload new software. |
| 60:29 FATAL ERROR INVALID FONT | Internal error during memory read. | - | Press control knob/start button to retry. If persists, upload new software. |
