Brand: Electrolux
Category: Air Conditioner
Document Type: Manual
Language: EN
Manual for EXP26U338CW
Uploaded: Sept. 12, 2025, 4:16 a.m.
Warranty Information
Consult your local service center for warranty details, typically 24 months.
Air Conditioner Operation
Cooling Mode: Use exhaust hose. Press 'mode' until 'Cool' is lit, select fan speed, and set temperature. Drainage is not required.
Heating Mode (if applicable): Use exhaust hose. Press 'mode' until 'Heat' is lit, select fan speed, and set temperature. Connect drain hose.
Dry Mode: Press 'mode' until 'Dry' is lit. Screen shows room temperature and 'low' fan indicator. Fan speed cannot be selected.
Fan Mode: No exhaust or drain hose needed. Press 'mode' until 'Fan' is lit, select fan speed. Auto speed cannot be selected.
Auto Mode: Always attach exhaust hose. Unit automatically selects cooling, heating, or fan mode based on selected and room temperature. Fan speed cannot be selected.
Timer Mode: Delay startup or shutdown. Press 'timer', set hours (0.5-24 hr increments). Unit starts/shuts down after set time.
Sleep Mode: Activate in Cool, Heat, or Auto mode. Fan speed becomes 'auto'. Temperature adjusts gradually for 7 hours.
Louver Swing: Press 'swing' for oscillating louvers.
°F/°C: Press '+' and '-' simultaneously for 3 seconds to switch units (not available in Dry/Fan mode).
Filter Reset: Press 'filter reset' after cleaning the filter to turn off the indicator.
Troubleshooting and error codes
| Warning | Meaning |
|---|---|
| Plug in power plug properly | Otherwise, it may cause electric shock, fire and explosion due to excess heat generation |
| Do not operate or stop the unit by inserting or pulling out Die power plug | It may cause electric shock, fire and explosion due to heat generation |
| Do not damage or use an unspecified power cord | It may cause electric shock, fire and explosion. If the power cord is damaged, it must be replaced by the manufacturer or an authorised service centre or a similarly qualified person in order to avoid a hazard |
| Do not modify power cord length or share the outlet with other appliances | It may cause electric shock, fire and explosion due to heat generation |
| Do not operate with wet hands or in damp environment | It may cause electric shock |
| Do not direct airflow at room occupants | This could harm your health |
| Always ensure effective earthing | Incorrect earthing may cause electric shock |
| Do not allow water to run into electric parts | It may cause failure of unit or electric shock |
| Always install circuit breaker and a dedicated power circuit | Incorrect installation may cause electric shock, fire and explosion |
| Unplug the unit if strange sounds, smell, or smoke comes from it | It may cause electric shock, fire and explosion |
| Do not use the socket if it is loose or damaged | It may cause electric shock, fire and explosion |
| Do not open the unit during operation | It may cause electric shock, fire and explosion |
| Keep firearms away | It may cause fire and explosion |
| Do not use the power cord close to heating appliances | It may cause electric shock, fire and explosion |
| Do not use the power cord near flammable gas or combustibles, such as gasoline, benzene, thinner, etc. | It may cause electric shock, fire and explosion |
| Ventilate room before operating air conditioner if there is a gas leakage from another appliance | It may cause explosion, fire, explosion and burns |
| Do not disassemble or modify unit | It may cause failure and electric shock |
