Manual for PORTABLE AIR CONDITIONER 3 IN 1
Uploaded: April 20, 2026, 7:44 p.m.
Warranty Information
Keep the manual and warranty card for future reference. Pass instructions to the next owner if applicable.
Basic Operation
- Turn on the device using the power key.
- Adjust temperature and time settings using Up/Down keys (temperature cannot be set in dehumidifying mode).
- Set fan speed to high or low.
- Engage Sleep mode for energy-saving and quiet operation.
- Select Cooling, Dehumidifier, or Fan mode.
- In Dehumidifier mode, only the fan operates at low speed.
- The "Water full light" indicates the tank needs draining and the device will stop.
- Set the timer for 1 to 24 hours.
Troubleshooting and error codes
| PROBLEM | POSSIBLE CAUSE | SOLUTION |
|---|---|---|
| The air conditioner does not work. | There is no electricity. | Turn it on after connecting it to a socket with electricity. |
| The overflow indicator displays "FL". | Discharge the water inside. | |
| The ambient temperature is too low or too high. | Recommend to use the machine in at the temperature of 7-35 °C (44-95 °F). | |
| The cooling effect is not good. | In cooling mode, the room temperature is lower than the set temperature. | Change the set temperature. |
| In dehumidification mode, the ambient temperature is low. | The machine is placed in a room with an ambient temperature over 17 °C (62 °F). | |
| There is direct sunlight. | Pull the curtains. | |
| Doors or windows are open; there are a lot of people; or in cooling mode, there are other sources of heat. | Close doors and windows, and add new air conditioner. | |
| Big Noise. | The filter screen is dirty. | Clean or replace the filter screen. |
| The air inlet or outlet is blocked. | Clear obstructions. | |
| The air conditioner is not placed on a flat surface. | Put the air conditioner on a flat and hard place (to reduce noise). | |
| Compressor does not work. | Overheat protection starts. | Wait for 3 minutes until the temperature is lowered, and then restart the machine. |
| The remote control does not work. | The distance between the machine and the remote control is too far. | Let the remote control get close to the air conditioner, and make sure that the remote control directly faces to the direction of the remote control receiver. |
| The remote control is not aligned with the direction of the remote control receiver. | Let the remote control get close to the air conditioner, and make sure that the remote control directly faces to the direction of the remote control receiver. | |
| Batteries are dead. | Replace batteries. | |
| Displays 'E1'. | The pipe temperature sensor is abnormal. | Check the pipe temperature sensor and related circuitry. |
| Displays 'E2'. | The room temperature sensor is abnormal. | Check the room temperature sensor and related circuitry. |
