Manual for Conga 1590 Active
Uploaded: April 20, 2026, 7:50 p.m.
Warranty Information
This product has a 2-year warranty from the date of purchase, provided it is used correctly.
- On/off Button: Press to turn on the robot. From standby mode, press to activate auto-cleaning. Press and hold for 3-5 seconds to enter network configuration. Press and hold for 7 seconds to enter standby mode. During operation, press to stop cleaning. During charging, press to activate auto-cleaning.
- Wi-Fi Indicator: Slowly flashes white when entering network configuration. Solid white when connected to Wi-Fi. Flashes rapidly if connection fails.
- Battery Indicator: Red when battery is low. Alternates between red and blue during charging. Solid blue when fully charged.
- Battery Charging: Place charging base against a wall, ensuring safety distances. Connect charger to robot and power outlet. Always turn the robot on before placing it on the base.
- Remote Control: Use buttons for navigation, power, water intensity, scheduling, and mode selection.
- Cleaning Modes: Auto, Edge, Area, Random, Twice, Scrubbing, Gyro, Manual, Return to base.
- Maintenance: Clean side brushes, dust tank, filters, sensors, and wheels regularly.
Troubleshooting and error codes
| Error | Cause | Solution | Display/Buttons | Beeps |
|---|---|---|---|---|
| 1 | Power button off | Check if the power switch is ON or OFF. | Robot display illuminates. | 1 long beep. |
| 2 | Left anti-fall sensor error | Place the robot on a flat, stable surface. | Robot display illuminates in blue and flashes rapidly. | 1 long beep. |
| 3 | Right anti-fall sensor error | Robot display illuminates in blue and flashes slowly. | 1 long beep. | |
| 4 | Front anti-fall sensor error | 1 long beep. | ||
| 5 | Left wheel does not touch the ground. | 1 long beep. | ||
| 6 | Right wheel does not touch the ground. | 1 long beep. | ||
| 7 | Left anti-collision sensor error | Clean or unblock the anti-collision sensors and bumpers. | Robot display illuminates in blue and red. | 1 long beep. |
| 8 | Right anti-collision sensor error | 1 long beep. | ||
| 9 | Front anti-collision sensor error | 1 long beep. | ||
| 10 | Left wheel error | Check if the brush or wheels are jammed or blocked and clean them. | Robot display flashes, switching from blue to red. | 1 long beep. |
| 11 | Right wheel error | 1 long beep. | ||
| 12 | Left side brush error | 1 long beep. | ||
| 13 | Right side brush error | 1 long beep. | ||
| 14 | Motor fan error | 1 long beep. | ||
| 15 | Main brush error | 1 long beep. | ||
| 17 | Low battery | Charge the robot. | Battery indicator illuminates red. | 4 short beeps. |
| 18 | Wi-Fi connection failed. | Check the Wi-Fi network status and try to connect again. | Wi-Fi indicator flashes rapidly. | 0 beeps. |
