Manual for QV-700
Uploaded: Aug. 9, 2025, 11:41 p.m.
Warranty Information
CASIO COMPUTER CO., LTD. assumes no responsibility for any damage or loss resulting from the use of this manual.
Recording Images
1. Enter Record Mode by sliding the function switch to REC.
2. Set the dial for normal recording.
3. Turn on the camera by sliding the POWER switch.
4. Set the NORMAL/MACRO switch to NORMAL (or MACRO for close-ups).
5. Press the F•N•E button to select the desired resolution (FINE, NORMAL, or ECONOMY).
6. Compose the image on the LCD and press the shutter button lightly to avoid movement.
Playing Back Images
1. Enter Playback Mode by sliding the function switch to PLAY.
2. Scroll through images using the [+] and [-] buttons.
3. Press the DISP button to cycle through display information (page number, date/time, etc.).
4. Use the MENU button for advanced playback options like Multi-Page Display, Zoom, Rotating, Filtering, Mixing, Auto Play, Folders, and Image Protection.
Connecting to Other Devices
1. Use the VIDEO OUT terminal with the special video cable to connect to TVs or video tape decks.
2. Use the DIGITAL terminal with the appropriate cable/kit to connect to PCs, other CASIO digital cameras, or a QV Color Printer.
3. Ensure all devices are powered off before connecting.
Troubleshooting and error codes
| Symptom | Probable Cause | Action |
|---|---|---|
| No power | 1. Batteries not loaded correctly. | 1. Correctly load batteries (page 22). |
| 2. Dead batteries | 2. Replace batteries with new ones (page 22). | |
| 3. Wrong AC adaptor | 3. Use only recommended AC adaptor. | |
| 4. Open memory card slot cover | 4. Securely close memory card slot cover. | |
| Sudden power failure | 1. Operation of Auto Power Off | 1. Turn power back on. |
| 2. Low battery power | 2. Replace batteries with new ones (page 22). | |
| indicator on LCD | Batteries are about to go dead. | Replace all four batteries with a set of new ones (page 22). |
| 3. Use of manganese batteries. | 3. Replace manganese batteries with alkaline batteries. | |
| No recording when shutter button is pressed | 1. Function switch sets to REC. | 1. Set function switch to PLAY. |
| 2. Insufficient memory card capacity or no memory card loaded in camera | 2. Load a memory card. | |
| Power failure during self-timer operation | Low battery power | Replace batteries (page 22). |
