Unpacking Your Camera

  1. Open the box and identify all included items: digital camera, rechargeable lithium ion battery (NP-130), USB-AC adapter (AD-C53U), USB cable, power cord, and Basic Reference guide.
  2. Attach the camera strap by threading it through the strap holes.

Charging the Battery

  1. Ensure the camera is turned off.
  2. Connect the USB cable to the camera and the USB-AC adapter. Plug the power cord into a household outlet. The back lamp will turn red when charging starts and go out when complete.
  3. Alternatively, connect the camera to a computer using the USB cable. The back lamp will turn amber while charging and green when complete.

Basic Settings

  1. Turn on the camera by pressing the [ON/OFF] button.
  2. Select the desired display language, date style, and then set the date and time using the control buttons. Press [SET] to confirm.
  3. Select "Apply" and press [SET] to finish basic settings.

Troubleshooting and error codes

Problem Possible Cause and Recommended Action
A recorded image was not saved. 1)Camera power may have been turned off before the save operation was complete, which will result in the image not being saved. If the battery indicator shows ■, charge the battery as soon as possible (page 21).
2)You may have removed the memory card from the camera before the save operation was complete, which will result in the image not being saved. Do not remove the memory card before the save operation is complete.
Though available lighting is bright, the faces of people in the image are dark. Not enough light is reaching the subjects. Change the flash mode setting to ☁ (Flash On) for daylight synchro flash (page 47), or adjust EV shift to the + side (page 46).
Night shots come out bad. Use the following BEST SHOT scenes (page 73) when shooting at night.
  • High Speed Night Scene (for shooting night scenery only)
  • High Speed Night Scene and Portrait (for shooting people against night scenery)
Subjects are too dark when shooting images in a seashore or ski area. Sunlight reflected by water, sand, or snow, can cause underexposure of images. Change the flash mode setting to ☁ (Flash On) for daylight synchro flash (page 47), or adjust EV shift to the + side (page 46).
Digital zoom will not go up to the maximum value. 1)The digital zoom setting may be turned off. Turn on digital zoom (page 99).
2)Zoom will not go up to the maximum value if the “Zoom (SR)” setting is "Single". Change the setting to “Off” (page 52).
3)Zoom will not go up to the maximum value if the snapshot size setting is "VGA”. Change to a different setting (page 42).
The image is out of focus during movie recording. 1)Focusing may not be possible because the subject is outside the focus range. Shoot within the allowable range.
2)The lens may be dirty. Clean the lens (page 174).
3)During High Speed Movie recording, focus is fixed at the position where it was when recording started. To focus an image, half-press the shutter button for Auto Focus or focus manually before you press [●] (Movie) to start recording.
Movie recording suddenly stops. The camera's protection function may have activated because camera temperature is too high. Wait until the camera temperature drops to normal levels.
