Manual for EX-FH20

The wrong date and time are displayed.

The date and time setting is off. Set the correct date and time (page 129).

The messages on the display are in the wrong language.

The wrong display language is selected. Change the display language setting (page 130).

Images cannot be transferred over a USB connection.

1) The USB cable may not be connected securely. Check all connections.
2) The wrong USB communication protocol is selected. Select the correct USB communication protocol (pages 113, 119).
3) If the camera is not turned on, turn it on.
4) Your computer may not be able to recognize the camera if you connect via a USB hub. Always connect directly to the computer's USB port.

Language selection screen appears when the camera is turned on.

1) You did not configure initial settings after purchasing the camera or the battery may have been left with dead batteries. Configure the correct settings (pages 15, 130).
2) There may be a problem with the camera's memory data. If this is the case, perform the reset operation to initialize the camera's setup (page 135). After that, configure each setting. If the language selection screen does not re-appear when you turn the camera on, it means that the camera's memory management data has been restored. If the same message appears after you turn power back on, contact your retailer or a CASIO authorized service center.

A lubricating agent is used to ensure that the lens operates smoothly. When the lens is extended, the lubricating agent can make it appear as if the lens-barrel unit is scratched. You can use a soft, dry cloth to wipe the lubricating agent off, if you want. When wiping off the lens-barrel unit, wipe gently taking care you do not twist the unit, or push it in, or pull it out. Note that the lubricating agent is not harmful to humans.

ALERT

The camera's protection function may have activated because camera temperature is too high. Turn off the camera and wait until it cools down before trying to use it again.

Battery is low.

Battery power is low.

Camera not in standby. Re-frame the image.

Move Out CS or Move In CS framing could not be performed for some reason, and so the camera cannot go into auto record standby. Perform the framing operation again (page 71).

Cannot find the file.

The image you specified with the slideshow “Images” setting cannot be found. Change the “Images” setting (page 95) and try again.

Cannot register any more files.

You are attempting to save a user BEST SHOT scene in the "SCENE” folder when the folder already contains 999 user scenes.

There is something wrong with the memory card. Turn off the camera, remove the memory card and then reload it into the camera. If this message re-appears when you turn the camera back on, format the memory card (page 135).

You are attempting to connect the camera to a printer while the camera's USB settings are not compatible with the USB system of the printer (page 106).

Battery power is low, so an image file could not be saved.

The flash is disabled for a short while to protect the flash unit after consecutive operations during Flash CS. You will be able to resume using the flash after this message disappears.

The flash needs to be fired by the flash unit is not open. Press ⬆ (Flash up) to open the flash unit.

Battery power is too low to fire the flash. Replace or charge the batteries as soon as possible.

You are trying to record a file while there are already 9999 files stored in the 999th folder. If you want to record more, delete files you no longer need (page 25).

This message appears and the camera turns off whenever lens performs some unexpected operation. If the same message appears after you turn power back on, contact a CASIO authorized service center or your original retailer.

The Anti Shake unit of the camera may be malfunctioning. If the same message appears after you turn power back on, contact your retailer or a CASIO service center.

The printer ran out of paper while printing.

Memory is full with images you recorded and/or files saved by editing operations. When shooting with Prerecord (Still image), this message indicates that there is not enough memory capacity to record all of the pre-recorded images. Delete files you no longer need (page 25).

An error occurred while printing. • The printer is turned off. • The printer generated an error, etc.

Image compression could not be performed for some reason during image data storage. Shoot the image again.

Your camera system is corrupted. Contact your retailer or an authorized CASIO authorized service center.

The LOCK switch of the SD or SDHC memory card loaded in the camera is in the locked position. You cannot store images to or delete images from a memory card that is locked.

There are no files in built-in memory or on the memory card.

There are currently no files specified for printing. Configure the required DPOF settings (page 108).

The setup you are trying to save is for an image that cannot be saved as a user BEST SHOT scene.

The memory card loaded in the camera is not formatted. Format the memory card (page 135).

The file you are trying to access is corrupted or is a type that cannot be displayed by this camera.

• You attempted to copy images from built-in memory to a memory card while there is no memory card loaded in the camera (page 103).
• You attempted to divide up a CS group while a file that is not a CS group is displayed (page 90).
