Highlights of the Camcorder

The Canon XA70 / XA75 4K Camcorder is a high-performance camcorder whose compact size makes it ideal in a variety of situations.

4K Recording

  • Advanced sensor and image processor: 1.0-inch CMOS sensor with DIGIC DV 6 imaging platform for nuanced images even in low-light.
  • XF-AVC and MP4 formats: Record in XF-AVC (MXF files) or MP4 format, both using MPEG-4 AVC/H.264 codec.
  • Wide zoom lens: 15x optical zoom lens with a focal length at full wide angle of 25.5 mm (35 mm equivalent).
  • Infrared recording: Record in darkness using infrared recording.
  • SD card recording options: Record 4K video in MP4 or XF-AVC format on SD cards, with dual or relay recording options.
  • Time code options: Output time code for synchronization with external devices.
  • Dual Pixel CMOS AF: Advanced autofocus with AF-boosted MF, face detection & tracking, and face-only AF.
  • Dual Pixel Focus Guide: Visual guide to check and adjust focus for sharp 4K video.

Convenience and Functionality

  • Emphasis on versatility: Compact size with advanced image stabilization for field use. Removable handle unit for audio options and infrared functionality.
  • Manual controls at your fingertips: Focus/zoom ring, customizable buttons and dials for easy operation.

Creativity and Artistic Expression

  • Special recording modes: Change frame rate for slow/fast motion or use pre-recording.
  • Looks: Adjust color depth, sharpness, and brightness to create a desired look, with preset options available.
  • Custom picture settings: Set gamma curve, color space, and color matrix for detailed image adjustments.

Other Features

  • Battery packs compatible with Intelligent System.
  • Optional GPS Receiver and Remote Controller compatibility.
  • Menu settings can be saved and restored.
  • UVC support for use as a webcam.

Troubleshooting and error codes

Issue/Symptom Possible Cause Solution
ACCESS indicator illuminated or flashing The memory card is being accessed. Do not disconnect power, open the card compartment, change operating mode, or disconnect USB cable while the indicator is on.
No image or light image on screen/viewfinder LCD panel or viewfinder issue. Rarely, pixels may misfire or light up permanently, which does not affect the recorded image and is not a malfunction.
