Manual for EasyMower 18V-32-200
Uploaded: Nov. 21, 2025, 8:41 p.m.
Manual Publish Date: 2022-05-17
Warranty Information
No specific warranty period is mentioned in the provided text.
Starting Operation
Insert the charged battery. Ensure the battery is inserted correctly.
To start the mower, insert the isolator switch and then the on/off switch.
To stop the mower, release the on/off switch.
Working Advice
Cut more frequently, increase the cutting height and walk at an appropriate pace for better cutting capacity.
Maintenance
Always wear gardening gloves. Keep nuts, bolts and screws tight. Inspect and replace worn parts. Ensure replacement parts are Bosch-approved. Keep the product clean and free of residue.
Troubleshooting and error codes
| Problem | Possible Cause | Corrective Measure |
|---|---|---|
| Motor refuses to start | Internal wiring of garden tool defective | Contact Bosch customer service agent |
| Battery discharged | Recharge battery | |
| Battery too hot/cold | Allow to cool/warm | |
| Grass too long | Max. allowed grass height 15 cm on highest height-of-cut setting | |
| Motor protector has activated | Allow motor to cool and increase height of cut | |
| Garden tool functions intermittently | Internal wiring of garden tool defective | Fit correctly |
| Motor protector has activated | Contact Bosch customer service agent | |
| Machine leaves ragged finish and/or Motor labours | Height of cut too low | Increase height of cut |
| Cutting blade blunt | Replace cutting blade (see figure K). | |
| Possible clogging | Switch garden tool off and disengage isolator key. Check underneath the garden product and clear out as necessary (always wear protective gloves). | |
| Blade not rotating while garden product switched on | Blade fitted upside down | Refit blade correctly. |
| Cutting blade obstructed | Switch garden tool off and disengage isolator key. Clear obstruction (always wear protective gloves). | |
| Belt drive separated | Contact Bosch customer service agent. | |
| Excessive vibrations/ noise | Blade nut/bolt loose | Tighten blade nut/bolt (17 Nm). |
| Cutting blade damaged | Replace cutting blade (see figure K). |
