Manual for WTE84106GB
Uploaded: Nov. 21, 2025, 7:59 p.m.
Warranty Information
Refer to the warranty information provided separately.
Operating Your Dryer
Preparing Laundry
Sort laundry by fabric type and drying program. Remove items from pockets and close zips/buttons. Do not over-dry easy-care fabrics. For delicate fabrics requiring low heat, select the 'Low Heat' option. Always spin laundry thoroughly in the washing machine before drying.
Selecting and Adjusting Programs
Turn the programme selector to choose a program (e.g., Cottons, Easy-Care, Sportswear). Adapt to individual requirements by adjusting dryness levels using the 'Fine adjustment' option (0-3). Press the 'Start/Stop' button to begin.
Drying Process
Empty the condensate container after each use. Clean the fluff filter after each drying operation. The dryer automatically stops when the program ends, indicated by lights on the display. An anti-crease function keeps laundry loose for an hour after the cycle.
Interrupting and Finishing
You can interrupt the cycle to add or remove laundry by opening the door. Close the door, select the program again if needed, and press 'Start/Stop'. To switch off, turn the programme selector to 'Off'. Remove laundry promptly.
Troubleshooting and error codes
| What to do if ... | Cause | Remedy |
|---|---|---|
| The Start/Stop indicator lamp does not light up. | Mains plug plugged in? Programme selected? | Check plug and programme selection. |
| The display panel light and indicator lights (depending on model) go out and the Start/Stop indicator light flashes. | Check the socket fuse. Energy-saving mode is activated. | Check fuse. Refer to Energy-saving mode instructions. |
| The Container and Start/Stop indicator lights are flashing. | Empty the condensate container. | Empty the container. Check condensation outlet hose if fitted. |
| The Clean and Start/Stop indicator lights are flashing. | Clean the fluff filter and/or air cooler under running water. | Clean filter and air cooler as described on pages 4/6. |
| Dryer does not start. | Start/Stop button selected? Door closed? Programme set? Ambient temperature greater than 5°C? | Press Start/Stop button. Close door securely. Select programme. Ensure ambient temperature is sufficient. |
| Water is running out. | Align dryer horizontally. Clean air cooler seal. | Level the dryer. Clean the seal. |
| The door opens by itself. | Push the door closed until you hear it engage. | Ensure the door is properly closed. |
| Creasing. | Laundry load exceeded? Unsuitable programme selected? | Reduce load. Select appropriate programme (Page 7). Select 'Low Heat' for delicates. Do not over-dry. |
| Laundry is not dried correctly or is still too damp. | Drying has been interrupted. Moisture sensors dirty. Exceeded maximum load. | Restart programme. Clean moisture sensors (Page 6). Reduce load. Select a program with longer drying time or higher dryness level. |
| Drying time too long. | Humidity in the room is high. Blocked air inlet. Ambient temperature too high. | Ventilate room. Clear air inlet (Page 8). Ensure adequate room ventilation. |
| The humidity in the room increases significantly. | Remove laundry from dryer immediately and spread out. | Allow laundry to cool. |
| Power failure. | Clean filter and air cooler. Check installation conditions. Restart programme. | Follow steps for filter/air cooler cleaning and installation checks. Restart. |
| One or more indicator lights for programme status are flashing. | Switch off, leave to cool down, switch on again, restart programme. | Perform reset by switching off and on. |
| The interior light is not working (depending on model). | Bulb is defective. | Replace bulb (Page 10). |
