Warranty Information

No specific warranty period information found in the provided pages.

Basic Operation:

  • Cool Mode: Select COOL mode, set desired temperature using TEMP buttons, and adjust fan speed (AU-100%). Press ON/OFF to start.
  • Dry Mode: Select DRY mode, set desired temperature. Fan speed cannot be adjusted. Press ON/OFF to start.
  • Fan Mode: Select FAN mode and adjust fan speed (AU-100%). Temperature cannot be set. Press ON/OFF to start.
  • Heat Mode: Select HEAT mode, set desired temperature, and adjust fan speed (AU-100%). Press ON/OFF to start. Note: Performance may be affected by low outside temperatures.

Timer Functions:

  • TIMER ON: Press TIMER button, then adjust desired ON time using TEMP buttons. Confirm with remote.
  • TIMER OFF: Press TIMER button, then adjust desired OFF time using TEMP buttons. Confirm with remote.
  • TIMER ON & OFF: Set separate ON and OFF times. Times are relative to the current hour.

Advanced Features:

  • Swing: Adjusts the horizontal (by pressing SWING repeatedly) or vertical (by pressing and holding SWING for over 2 seconds) angle of the louvers.
  • ECO/GEAR: Energy-saving modes. ECO adjusts temperature and fan speed for efficiency. GEAR reduces power consumption to 75% or 50%. Only available in COOL mode.
  • GoClean: Automatically cleans the unit by freezing and thawing frost. Available in COOL or DRY mode.
  • Silence: Reduces compressor frequency for quieter operation, potentially affecting cooling/heating capacity.
  • FP (Anti-frost): For heat pump models, activates frost protection in HEAT mode with a set temperature of 8°C/46°F.
  • Lock: Disables all buttons except for unlocking (press GoClean and Turbo simultaneously for over 5 seconds).
  • SET: Used to cycle through and set various functions.
  • Breeze Away: Avoids direct airflow onto the body. Available in COOL, FAN, and DRY modes.
  • Sleep: Adjusts temperature automatically for comfortable sleep. Available in COOL, HEAT, AUTO modes.
  • ZoneFollow: The remote measures room temperature and sends it to the unit. Memory function can be activated/deactivated.
  • AP Mode: For Wi-Fi network configuration.
  • HygieneMax: Uses UV-C light to sterilize air.

Troubleshooting and error codes

Common Issues Possible Causes Solutions
Unit does not start. Power is turned off. Check if the power cord is plugged in and the circuit breaker is ON.
Remote control is not working. Check batteries. Ensure the remote is pointed at the unit.
Not cooling/heating effectively. Air filters are dirty. Clean the air filters.
Set temperature is not appropriate. Adjust the set temperature.
Doors or windows are open. Close doors and windows.
Water leakage. Drainage pipe is blocked or improperly installed. Check and clear the drainage pipe. Ensure proper installation.
Unusual noise. Unit is not installed on a level surface. Ensure the unit is installed on a stable, level surface.
Obstruction near the unit. Remove any obstructions.
Error codes displayed (e.g., "ELOC"). Refrigerant leakage detected. Call service personnel immediately.
