Getting your device ready
Before you can start using your device, you need to install a Subscriber Identity Mode (SIM) card and a charged battery.
Installing the SIM card and battery
1. Remove the battery compartment cover then remove battery.
2. Insert the SIM card with its gold contacts facing down and the notched corner oriented to the upper left corner of the slot.
3. Replace the battery into the compartment with its copper contacts properly aligned to the copper conductor on the device.
4. Replace battery compartment cover.
Charging the battery
The bundled battery pack is shipped only partially charged. Make sure to charge the battery at least four hours before using it for the first time.
To charge the battery:
1. Connect the AC adapter plug to the mini-USB connector at the bottom of the device.
2. Connect the AC power plug to a grounded wall socket or power strip.
Powering your device
After charging the battery, you are now ready to use your device.
To power on your device:
1. Press and hold the power button to turn ON the device.
2. Follow the succeeding screen instructions to setup your Windows Mobile-based device.
The Today screen
The Today screen displays information useful to you.
