Manual for OPTIMA 105
Uploaded: Aug. 9, 2025, 11:36 p.m.
Warranty Information
Contact the distributor or manufacturer for service, support, and warranty information.
- **Power On/Off:** Press the Power button.
- **Taking Images:** Ensure the camera is in Photo Mode. Frame the shot using the LCD, then press the Shutter button halfway to focus and fully to capture.
- **Zooming:** Use the Zoom dial to zoom in (clockwise) or out (counterclockwise).
- **Flash:** Press the Flash/Right button to cycle through flash modes (Auto, Red-eye, Forced On, Slow Sync, Forced Off).
- **Focus:** Use the Macro/Left button to select focus modes (Normal, Macro, Pan Focus, Infinity).
- **Function Menu:** Press the FUNC button to access settings like Photo Size, Quality, White Balance, ISO, and Metering.
- **Playback:** Slide the mode switch to Playback Mode to view images and videos.
Troubleshooting and error codes
| Problem | Cause and/or Action |
|---|---|
| Camera does not turn on. | The batteries may be exhausted. Charge or replace the batteries. |
| Camera turns off automatically. | Press Power button to turn on the camera. |
| LCD turns blank. | Press any button except the Power button to turn on the LCD. |
| Empty battery icon is displayed on the LCD, then the camera turns off. | Batteries are exhausted, please replace or recharge. |
| LCD monitor displays 'No image'. | There is no image file in the memory card. Image file format may not be supported. |
| LCD monitor displays 'Not available for this file'. | Function is only available for specific file types. File format is not supported. |
| LCD monitor displays 'Memory full'. | Memory card is full. Replace the memory card with a new one or delete unnecessary images. |
| LCD monitor displays 'File locked' | This file is locked. Unlock the file. See "Protect" on page 46. |
| LCD monitor displays 'Card locked'. | The memory card is protected. Remove the card and slide the write-protect switch to its unlock position. |
| LCD monitor displays 'Format error'. | The card may be damaged. You can either change the card or wipe to clean the connected points. |
| LCD monitor displays 'Copy error'. | The memory card is protected. Remove the card and slide the write-protect switch to its unlock position. |
| No image displays on the TV screen. | Incorrect TV-out type was selected. Set the correct TV-out type to match your TV system. |
| The lens got stuck up. | Do not force the lens to go back. The type of the battery used may be incorrect or the battery power level is too low. Change the battery or charge the battery before using the camera. |
