Brand: AEG
Category: Home Appliances
Document Type: Manual
Language: EN
Manual for 49176IW-MN
Uploaded: April 20, 2026, 8:06 p.m.
Warranty Information
Refer to safety chapters for warranty information.
The manual provides comprehensive instructions for operating and maintaining the AEG cooker. It covers safety information, product description, hob and oven usage, clock functions, troubleshooting, installation, and energy efficiency. Key operations include setting the time, selecting cooking functions and temperatures, and using various timer functions. The hob has touch controls for zones, power function, and safety lock. The oven has multiple functions like conventional cooking, grilling, and special modes like Thermaflow® and Low Temperature Cooking. It also details the use of the core temperature sensor and various cleaning procedures for different parts of the appliance.
Troubleshooting and error codes
| Problem | Possible cause | Remedy |
|---|---|---|
| You cannot activate the appliance. | The appliance is not connected to an electrical supply or it is connected incorrectly. | Check if the appliance is correctly connected to the electrical supply. |
| You cannot activate the appliance. | The fuse is blown. | Make sure that the fuse is the cause of the malfunction. If the fuse is blown again and again, contact a qualified electrician. |
| You cannot activate or operate the hob. | You touched 2 or more sensor fields at the same time. | Touch only one sensor field. |
| You cannot activate or operate the hob. | STOP+GO function operates. | Refer to "Hob - Daily use" chapter. |
| You cannot activate or operate the hob. | There is water or fat stains on the control panel. | Clean the control panel. |
| An acoustic signal sounds and the hob deactivates. | You put something on one or more sensor fields. | Remove the object from the sensor fields. |
| An acoustic signal sounds when the hob is deactivated. | You put something on the sensor field. | Remove the object from the sensor fields. |
| The hob deactivates. | Automatic Switch Off operates. | Deactivate the hob and activate it again. |
| Residual heat indicator does not come on. | The zone is not hot because it operated only for a short time. | If the zone operated sufficiently long to be hot, speak to an Authorised Service Centre. |
| Automatic Heat Up function does not operate. | The zone is hot. | Let the zone become sufficiently cool. |
| Automatic Heat Up function does not operate. | The highest heat setting is set. | The highest heat setting has the same power as the function. |
| The sensor fields become hot. | The cookware is too large or you put it too near to the controls. | Put large cookware on the rear zones if possible. |
| There is no signal when you touch the panel sensor fields. | The signals are deactivated. | Activate the signals. Refer to "Hob - Daily use" chapter. |
| L comes on the hob display. | The Child Safety Device or the Lock function operates. | Refer to "Hob - Daily use" chapter. |
| F comes on the hob display. | There is no cookware on the zone. | Put cookware on the zone. |
| F comes on the hob display. | The cookware is incorrect. | Use the correct cookware. Refer to "Hob - Hints and tips" chapter. |
| F comes on the hob display. | The diameter of the bottom of the cookware is too small for the zone. | Use cookware with correct dimensions. Refer to "Hob - Hints and tips" chapter. |
| The oven does not heat up. | The oven is deactivated. | Activate the oven. |
| The oven does not heat up. | The clock is not set. | Set the clock. |
| The oven does not heat up. | The necessary settings are not set. | Make sure that the settings are correct. |
| The oven does not heat up. | The automatic switch-off is activated. | Refer to "Automatic switch-off". |
| The lamp does not operate. | The lamp is defective. | Replace the lamp. |
| The core temperature sensor does not operate. | The plug of the core temperature sensor is not correctly installed into the socket. | Put the plug of the core temperature sensor as far as possible into the socket. |
| It takes too long to cook the dishes or they cook too quickly. | The temperature is too low or too high. | Adjust the temperature if necessary. Follow the advice in the user manual. |
| Steam and condensation settle on the food and in the cavity of the oven. | You left the dish in the oven for too long. | Do not leave the dishes in the oven for longer than 15 - 20 minutes after the cooking process ends. |
| The display shows an error code that is not in this table. | There is an electrical fault. | Deactivate the appliance with the house fuse or the safety switch in the fuse box and activate it again. If the display shows the error code again, contact the Customer Care Department. |
