Brand: AEG
Category: Fridge Freezer
Document Type: Manual
Language: EN
Manual for 3510 KG
Uploaded: April 20, 2026, 8:08 p.m.
Manual Publish Date: 1993-12-01
Freezer Compartment Operation:
Press the On/Off switch (3). The green mains pilot lamp (3) and red temperature pilot lamp (5) will illuminate. An audible alarm may sound. The green lamp indicates operation; it should remain lit. The red lamp and alarm signal that the desired temperature has not been reached or has been exceeded. Press the fast-freeze switch (4) if necessary. The amber fast-freeze pilot lamp (4) will light up, and the unit will run continuously. The alarm stops when fast-freeze is activated. Switch off fast-freeze when the red lamp goes out. The temperature regulator (2) adjusts the freezer temperature between settings 1 (warmest) and 4 (coldest).
Refrigerator Compartment Operation:
Press the On/Off switch (9). The green mains pilot lamp (9) will illuminate, indicating operation. The temperature regulator (8) adjusts the refrigerator temperature between settings 1 (warmest) and 4 (coldest).
Troubleshooting and error codes
| Potential Fault | Possible Cause | Remedy |
|---|---|---|
| Green light goes out | Fast-freeze system not activated | Switch on fast-freeze system. |
| Amber light on, green light off | Green light is defective | Replace green light. |
| Amber light does not come on, refrigerating unit operational | Amber light needs replacement | Replace amber light. |
| Neither pilot light is on | Power supply issue | Check mains plug, house fuse, or overall power failure. Contact electrician if necessary. |
| Red light on and audible alarm sounding, or sharp rise in freezer temperature without fresh food insertion or long door opening | Fault | Switch on fast-freeze system, keep door closed, contact service centre. Do not attempt repairs yourself. |
